Test Date: 2016-10-26 15:39
Analysis date: 2016-10-26 16:48
Analysis date: 2016-10-26 16:48
M1044 XRayHRQualification
Summary
| Module | Module | M1044 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.55 | % |
| Noise | Mean Noise | 321 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.81 | 99.55 | 0.42 | 69.3 | 222.2 | 0 | 0/0 | 0 | 3514 | 341 | 945 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.57 | 0.32 | 66.5 | 209.6 | 0 | 0/0 | 0 | 3783 | 344 | 997 |
|
Chip 2
|
A
|
0 | 0 | 99.84 | 99.60 | 0.32 | 78.5 | 248.6 | 0 | 0/0 | 0 | 3734 | 347 | 1095 |
|
Chip 3
|
A
|
0 | 0 | 99.82 | 99.55 | 0.28 | 49.6 | 152.5 | 0 | 0/0 | 0 | 3843 | 312 | 582 |
|
Chip 4
|
A
|
0 | 0 | 99.81 | 99.73 | 0.22 | 39.8 | 121.8 | 0 | 0/0 | 0 | 3853 | 299 | 401 |
|
Chip 5
|
A
|
0 | 0 | 99.83 | 99.45 | 0.22 | 47.4 | 145.5 | 1 | 0/0 | 0 | 3810 | 325 | 721 |
|
Chip 6
|
A
|
0 | 0 | 99.82 | 99.52 | 0.24 | 44.2 | 135.5 | 0 | 0/0 | 0 | 3590 | 315 | 572 |
|
Chip 7
|
A
|
0 | 0 | 99.83 | 99.18 | 0.2 | 41.2 | 127.1 | 0 | 0/0 | 0 | 3894 | 307 | 482 |
|
Chip 8
|
A
|
0 | 0 | 99.82 | 99.71 | 0.18 | 40.6 | 125.7 | 0 | 0/0 | 0 | 3877 | 299 | 395 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.73 | 0.27 | 44.2 | 136.0 | 0 | 0/0 | 0 | 3877 | 295 | 355 |
|
Chip 10
|
A
|
0 | 0 | 99.81 | 99.53 | 0.28 | 49.5 | 150.7 | 0 | 0/0 | 0 | 3840 | 314 | 560 |
|
Chip 11
|
A
|
0 | 0 | 99.82 | 99.55 | 0.21 | 43.8 | 132.8 | 0 | 0/0 | 0 | 3784 | 330 | 821 |
|
Chip 12
|
A
|
0 | 0 | 99.84 | 99.54 | 0.2 | 40.2 | 123.0 | 0 | 0/0 | 0 | 3829 | 285 | 260 |
|
Chip 13
|
A
|
1 | 0 | 99.82 | 99.56 | 0.36 | 72.7 | 224.9 | 1 | 0/0 | 0 | 3762 | 339 | 904 |
|
Chip 14
|
A
|
0 | 0 | 99.81 | 99.57 | 0.38 | 64.6 | 200.9 | 0 | 0/0 | 0 | 3808 | 334 | 862 |
|
Chip 15
|
A
|
0 | 0 | 99.79 | 99.48 | 0.37 | 82.0 | 257.5 | 0 | 0/0 | 0 | 3762 | 349 | 1086 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-26 | |
| TestTime | Test Time | 15:39 | |
| TestDuration | Duration | 0:59:47 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-11-g3f3decf on branch master
