Test Date: 2016-10-26 15:39
Analysis date: 2016-10-26 16:46
Analysis date: 2016-10-26 16:46
M1043 XRayHRQualification
Summary
| Module | Module | M1043 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 8 | |
| BumpBondingDefects | Bump Bonding Defects | 2 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.57 | % |
| Noise | Mean Noise | 340 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.81 | 99.72 | 0.25 | 68.2 | 203.4 | 0 | 0/0 | 0 | 3509 | 335 | 835 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 99.55 | 0.28 | 67.7 | 198.1 | 0 | 0/0 | 0 | 3574 | 317 | 643 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.60 | 0.3 | 86.7 | 257.4 | 0 | 0/0 | 0 | 3691 | 356 | 1218 |
|
Chip 3
|
A
|
1 | 0 | 99.81 | 99.60 | 0.22 | 59.4 | 178.2 | 0 | 0/0 | 0 | 3783 | 326 | 765 |
|
Chip 4
|
A
|
1 | 0 | 99.80 | 99.52 | 0.32 | 68.3 | 205.0 | 0 | 0/0 | 0 | 3724 | 345 | 1003 |
|
Chip 5
|
A
|
4 | 0 | 99.83 | 99.56 | 0.27 | 94.7 | 285.2 | 0 | 0/0 | 0 | 3717 | 362 | 1271 |
|
Chip 6
|
A
|
0 | 0 | 99.83 | 99.62 | 0.24 | 75.2 | 223.6 | 0 | 0/0 | 0 | 3781 | 335 | 914 |
|
Chip 7
|
A
|
0 | 0 | 99.82 | 99.57 | 0.36 | 92.8 | 273.9 | 0 | 0/0 | 0 | 3765 | 341 | 1008 |
|
Chip 8
|
A
|
1 | 0 | 99.78 | 99.45 | 0.49 | 101.9 | 304.6 | 1 | 0/0 | 0 | 3775 | 367 | 1364 |
|
Chip 9
|
A
|
0 | 0 | 99.81 | 99.61 | 0.28 | 85.9 | 255.3 | 0 | 0/0 | 0 | 3751 | 337 | 939 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.60 | 0.28 | 91.7 | 275.0 | 0 | 0/0 | 0 | 3777 | 341 | 1050 |
|
Chip 11
|
A
|
0 | 0 | 99.79 | 99.51 | 0.33 | 63.9 | 193.3 | 0 | 0/0 | 0 | 3788 | 326 | 759 |
|
Chip 12
|
A
|
0 | 0 | 99.83 | 99.55 | 0.23 | 52.6 | 157.3 | 0 | 0/0 | 0 | 3828 | 312 | 559 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 99.50 | 0.35 | 76.6 | 231.1 | 0 | 0/0 | 0 | 3706 | 362 | 1224 |
|
Chip 14
|
A
|
0 | 0 | 99.83 | 99.54 | 0.27 | 72.5 | 215.5 | 0 | 0/0 | 0 | 3723 | 337 | 899 |
|
Chip 15
|
A
|
1 | 0 | 99.79 | 99.59 | 0.28 | 79.0 | 237.3 | 1 | 0/0 | 0 | 3741 | 337 | 940 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-26 | |
| TestTime | Test Time | 15:39 | |
| TestDuration | Duration | 0:59:47 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 13 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-11-g3f3decf on branch master
