Test Date: 2016-10-26 14:26
Analysis date: 2016-10-26 15:46
Analysis date: 2016-10-26 15:46
M1040 XRayHRQualification
Summary
| Module | Module | M1040 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 9 | |
| BumpBondingDefects | Bump Bonding Defects | 7 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.58 | % |
| Noise | Mean Noise | 330 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.82 | 99.51 | 0.22 | 66.6 | 201.8 | 0 | 0/0 | 0 | 3768 | 321 | 684 |
|
Chip 1
|
A
|
2 | 0 | 99.82 | 99.53 | 0.21 | 65.8 | 196.9 | 2 | 0/0 | 0 | 3548 | 326 | 733 |
|
Chip 2
|
A
|
2 | 0 | 99.82 | 99.58 | 0.37 | 78.1 | 234.9 | 3 | 0/0 | 0 | 3668 | 330 | 880 |
|
Chip 3
|
A
|
2 | 0 | 99.83 | 99.63 | 0.18 | 50.6 | 152.3 | 2 | 0/0 | 0 | 3849 | 296 | 436 |
|
Chip 4
|
A
|
1 | 0 | 99.82 | 99.45 | 0.19 | 53.4 | 160.5 | 1 | 0/0 | 0 | 3520 | 315 | 614 |
|
Chip 5
|
A
|
0 | 0 | 99.81 | 99.64 | 0.31 | 77.3 | 233.6 | 0 | 0/0 | 0 | 3759 | 346 | 1050 |
|
Chip 6
|
A
|
0 | 0 | 99.80 | 99.56 | 0.46 | 85.7 | 256.8 | 1 | 0/0 | 0 | 3650 | 351 | 1149 |
|
Chip 7
|
A
|
1 | 0 | 99.82 | 99.55 | 0.33 | 86.0 | 258.1 | 1 | 0/0 | 0 | 3833 | 342 | 1003 |
|
Chip 8
|
A
|
1 | 0 | 99.81 | 99.64 | 0.3 | 76.9 | 233.8 | 1 | 0/0 | 0 | 3761 | 319 | 685 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.59 | 0.25 | 82.1 | 252.3 | 0 | 0/0 | 0 | 3774 | 338 | 933 |
|
Chip 10
|
A
|
0 | 0 | 99.83 | 99.56 | 0.47 | 81.9 | 248.0 | 0 | 0/0 | 0 | 3857 | 349 | 1115 |
|
Chip 11
|
A
|
0 | 0 | 99.80 | 99.49 | 0.25 | 56.8 | 170.5 | 0 | 0/0 | 0 | 3673 | 330 | 759 |
|
Chip 12
|
A
|
0 | 0 | 99.83 | 99.61 | 0.19 | 52.2 | 157.4 | 0 | 0/0 | 0 | 3793 | 322 | 693 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 99.57 | 0.25 | 71.8 | 218.9 | 0 | 0/0 | 0 | 3534 | 335 | 874 |
|
Chip 14
|
A
|
0 | 0 | 99.83 | 99.78 | 0.21 | 62.7 | 194.5 | 0 | 0/0 | 0 | 3776 | 341 | 965 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 99.62 | 0.28 | 68.6 | 208.8 | 0 | 0/0 | 0 | 3798 | 326 | 765 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-26 | |
| TestTime | Test Time | 14:26 | |
| TestDuration | Duration | 0:59:23 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-11-g3f3decf on branch master
