Test Date: 2016-10-31 10:19
Analysis date: 2016-10-31 11:26
Analysis date: 2016-10-31 11:26
M1038 XRayHRQualification
Summary
| Module | Module | M1038 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.53 | % |
| Noise | Mean Noise | 300 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.83 | 99.52 | 0.27 | 63.9 | 200.5 | 0 | 0/0 | 0 | 3867 | 308 | 545 |
|
Chip 1
|
A
|
0 | 0 | 99.80 | 99.63 | 0.9 | 52.8 | 163.4 | 0 | 0/0 | 0 | 3892 | 303 | 402 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.51 | 0.24 | 51.5 | 160.9 | 0 | 0/0 | 0 | 3629 | 306 | 472 |
|
Chip 3
|
A
|
0 | 0 | 99.81 | 99.61 | 0.21 | 46.9 | 144.4 | 0 | 0/0 | 0 | 3844 | 341 | 978 |
|
Chip 4
|
A
|
0 | 0 | 99.82 | 99.79 | 0.12 | 35.7 | 108.2 | 0 | 0/0 | 0 | 3932 | 284 | 252 |
|
Chip 5
|
A
|
0 | 0 | 99.82 | 99.57 | 0.16 | 43.6 | 135.0 | 0 | 0/0 | 0 | 3924 | 281 | 255 |
|
Chip 6
|
A
|
0 | 0 | 99.82 | 98.78 | 0.09 | 27.8 | 85.3 | 0 | 0/0 | 0 | 3987 | 238 | 86 |
|
Chip 7
|
A
|
0 | 0 | 99.81 | 99.64 | 0.21 | 38.5 | 118.5 | 0 | 0/0 | 0 | 3874 | 311 | 510 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 100.30 | 0.19 | 32.9 | 102.7 | 0 | 0/0 | 0 | 3917 | 314 | 682 |
|
Chip 9
|
A
|
0 | 0 | 99.81 | 99.01 | 0.24 | 31.2 | 95.4 | 0 | 0/0 | 0 | 3958 | 273 | 162 |
|
Chip 10
|
A
|
0 | 0 | 99.81 | 99.47 | 0.32 | 56.0 | 171.1 | 0 | 0/0 | 0 | 3868 | 307 | 481 |
|
Chip 11
|
A
|
0 | 0 | 99.86 | 99.54 | 0.18 | 34.5 | 105.3 | 0 | 0/0 | 0 | 3947 | 268 | 165 |
|
Chip 12
|
A
|
0 | 0 | 99.78 | 99.52 | 0.25 | 35.3 | 107.2 | 0 | 0/0 | 0 | 3941 | 273 | 218 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 99.59 | 0.31 | 66.3 | 209.7 | 0 | 0/0 | 0 | 3753 | 347 | 1025 |
|
Chip 14
|
A
|
1 | 0 | 99.83 | 99.50 | 0.29 | 59.2 | 184.1 | 1 | 0/0 | 0 | 3839 | 314 | 567 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 99.53 | 0.32 | 67.6 | 212.1 | 0 | 0/0 | 0 | 3817 | 330 | 842 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-31 | |
| TestTime | Test Time | 10:19 | |
| TestDuration | Duration | 0:58:35 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
