Test Date: 2016-10-31 09:16
Analysis date: 2016-10-31 10:23
Analysis date: 2016-10-31 10:23
M1036 XRayHRQualification
Summary
| Module | Module | M1036 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.55 | % |
| Noise | Mean Noise | 332 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.84 | 99.62 | 0.21 | 59.9 | 183.1 | 1 | 0/0 | 0 | 3846 | 314 | 574 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.57 | 0.3 | 69.5 | 212.8 | 0 | 0/0 | 0 | 3752 | 348 | 1045 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.52 | 0.22 | 64.1 | 193.6 | 0 | 0/0 | 0 | 3827 | 307 | 485 |
|
Chip 3
|
A
|
0 | 0 | 99.82 | 99.60 | 0.19 | 45.4 | 135.5 | 0 | 0/0 | 0 | 3885 | 295 | 365 |
|
Chip 4
|
A
|
0 | 0 | 99.84 | 99.55 | 0.17 | 61.7 | 190.0 | 0 | 0/0 | 0 | 3786 | 333 | 888 |
|
Chip 5
|
A
|
0 | 0 | 99.83 | 99.55 | 0.34 | 73.3 | 222.0 | 0 | 0/0 | 0 | 3789 | 331 | 830 |
|
Chip 6
|
A
|
0 | 0 | 99.83 | 99.54 | 0.35 | 70.0 | 214.7 | 0 | 0/0 | 0 | 3811 | 330 | 805 |
|
Chip 7
|
A
|
0 | 0 | 99.82 | 99.54 | 0.39 | 96.6 | 298.7 | 0 | 0/0 | 0 | 3526 | 387 | 1630 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.54 | 0.36 | 76.3 | 234.8 | 0 | 0/0 | 0 | 3833 | 323 | 721 |
|
Chip 9
|
A
|
0 | 0 | 99.81 | 99.57 | 0.37 | 80.0 | 249.5 | 0 | 0/0 | 0 | 3801 | 348 | 1088 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.61 | 0.36 | 65.1 | 200.4 | 0 | 0/0 | 0 | 3751 | 327 | 752 |
|
Chip 11
|
A
|
0 | 0 | 99.82 | 99.57 | 0.3 | 55.2 | 168.0 | 0 | 0/0 | 0 | 3807 | 339 | 913 |
|
Chip 12
|
A
|
0 | 0 | 99.82 | 99.59 | 0.26 | 51.1 | 157.4 | 0 | 0/0 | 0 | 3852 | 324 | 689 |
|
Chip 13
|
A
|
0 | 0 | 99.80 | 99.50 | 0.34 | 62.9 | 192.5 | 0 | 0/0 | 0 | 3819 | 339 | 913 |
|
Chip 14
|
A
|
0 | 0 | 99.81 | 99.44 | 0.38 | 65.8 | 204.7 | 0 | 0/0 | 0 | 3529 | 339 | 985 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 99.51 | 0.26 | 58.1 | 177.3 | 0 | 0/0 | 0 | 3823 | 329 | 740 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-31 | |
| TestTime | Test Time | 09:16 | |
| TestDuration | Duration | 0:59:35 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 849 | |
| nWarnings | # Warnings | 153 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 126 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 51 | |
| message_readback_count | Readback start marker | 102 |
