Test Date: 2016-10-26 12:42
Analysis date: 2016-10-26 13:48
Analysis date: 2016-10-26 13:48
M1035 XRayHRQualification
Summary
| Module | Module | M1035 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.58 | % |
| Noise | Mean Noise | 339 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.82 | 99.64 | 0.23 | 64.6 | 194.4 | 0 | 0/0 | 0 | 3815 | 332 | 829 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 99.54 | 0.24 | 67.0 | 200.1 | 0 | 0/0 | 0 | 3757 | 324 | 675 |
|
Chip 2
|
A
|
0 | 0 | 99.84 | 99.60 | 0.26 | 71.2 | 219.7 | 0 | 0/0 | 0 | 3785 | 340 | 902 |
|
Chip 3
|
A
|
0 | 0 | 99.81 | 99.61 | 0.36 | 60.1 | 184.3 | 0 | 0/0 | 0 | 3739 | 376 | 1414 |
|
Chip 4
|
A
|
1 | 0 | 99.80 | 99.41 | 0.26 | 59.2 | 179.2 | 1 | 0/0 | 0 | 3757 | 342 | 893 |
|
Chip 5
|
A
|
0 | 0 | 99.82 | 99.58 | 0.23 | 72.9 | 220.8 | 0 | 0/0 | 0 | 3782 | 339 | 911 |
|
Chip 6
|
A
|
0 | 0 | 99.82 | 99.61 | 0.31 | 83.1 | 256.2 | 0 | 0/0 | 0 | 3754 | 360 | 1240 |
|
Chip 7
|
A
|
0 | 0 | 99.83 | 99.60 | 0.3 | 75.0 | 231.9 | 0 | 0/0 | 0 | 3835 | 321 | 728 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.57 | 0.38 | 96.4 | 297.4 | 0 | 0/0 | 0 | 3822 | 352 | 1158 |
|
Chip 9
|
A
|
0 | 0 | 99.83 | 99.62 | 0.2 | 73.1 | 218.4 | 0 | 0/0 | 0 | 3824 | 303 | 459 |
|
Chip 10
|
A
|
0 | 0 | 99.83 | 99.58 | 0.31 | 79.4 | 241.1 | 0 | 0/0 | 0 | 3786 | 338 | 958 |
|
Chip 11
|
A
|
0 | 0 | 99.83 | 99.60 | 0.26 | 58.6 | 176.3 | 0 | 0/0 | 0 | 3794 | 339 | 950 |
|
Chip 12
|
A
|
0 | 0 | 99.81 | 99.58 | 0.28 | 58.5 | 177.8 | 0 | 0/0 | 0 | 3756 | 356 | 1110 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 99.56 | 0.29 | 71.5 | 217.7 | 0 | 0/0 | 0 | 3560 | 316 | 587 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 99.64 | 0.25 | 75.8 | 231.4 | 0 | 0/0 | 0 | 3779 | 337 | 894 |
|
Chip 15
|
A
|
0 | 0 | 99.84 | 99.61 | 0.29 | 82.4 | 253.3 | 0 | 0/0 | 0 | 3744 | 344 | 1055 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-26 | |
| TestTime | Test Time | 12:42 | |
| TestDuration | Duration | 0:57:26 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
