Test Date: 2016-10-26 12:42
Analysis date: 2016-10-26 13:44
Analysis date: 2016-10-26 13:44
M1033 XRayHRQualification
Summary
| Module | Module | M1033 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 3 | |
| BumpBondingDefects | Bump Bonding Defects | 3 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.59 | % |
| Noise | Mean Noise | 312 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.80 | 99.52 | 0.38 | 72.9 | 226.6 | 0 | 0/0 | 0 | 3825 | 327 | 760 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.59 | 0.27 | 72.8 | 225.2 | 0 | 0/0 | 0 | 3609 | 317 | 723 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.59 | 0.26 | 62.7 | 195.0 | 0 | 0/0 | 0 | 3794 | 312 | 580 |
|
Chip 3
|
A
|
0 | 0 | 99.81 | 99.61 | 0.29 | 48.5 | 147.5 | 0 | 0/0 | 0 | 3840 | 319 | 635 |
|
Chip 4
|
A
|
0 | 0 | 99.81 | 99.45 | 0.2 | 40.2 | 121.8 | 0 | 0/0 | 0 | 3905 | 287 | 305 |
|
Chip 5
|
A
|
0 | 0 | 99.84 | 99.55 | 0.24 | 52.3 | 161.9 | 0 | 0/0 | 0 | 3603 | 307 | 514 |
|
Chip 6
|
A
|
0 | 0 | 99.83 | 99.58 | 0.25 | 52.7 | 161.4 | 0 | 0/0 | 0 | 3387 | 305 | 520 |
|
Chip 7
|
A
|
0 | 0 | 99.82 | 99.83 | 0.24 | 42.5 | 130.6 | 0 | 0/0 | 0 | 3620 | 317 | 575 |
|
Chip 8
|
A
|
2 | 0 | 99.82 | 99.61 | 0.23 | 46.8 | 143.5 | 2 | 0/0 | 0 | 3843 | 349 | 1070 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.50 | 0.22 | 41.1 | 125.2 | 0 | 0/0 | 0 | 3909 | 302 | 394 |
|
Chip 10
|
A
|
1 | 0 | 99.82 | 99.53 | 0.16 | 39.3 | 120.3 | 1 | 0/0 | 0 | 3917 | 282 | 228 |
|
Chip 11
|
A
|
0 | 0 | 99.84 | 99.74 | 0.18 | 30.4 | 92.5 | 0 | 0/0 | 0 | 3967 | 253 | 120 |
|
Chip 12
|
A
|
0 | 0 | 99.82 | 99.56 | 0.3 | 41.6 | 125.5 | 0 | 0/0 | 0 | 3849 | 286 | 345 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 99.58 | 0.28 | 72.9 | 226.3 | 0 | 0/0 | 0 | 3648 | 338 | 913 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 99.58 | 0.35 | 70.9 | 221.5 | 0 | 0/0 | 0 | 3547 | 334 | 856 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 99.56 | 0.3 | 73.4 | 228.2 | 0 | 0/0 | 0 | 3731 | 357 | 1192 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-26 | |
| TestTime | Test Time | 12:42 | |
| TestDuration | Duration | 0:57:26 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 15 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-11-g3f3decf on branch master
