Test Date: 2016-10-26 11:39
Analysis date: 2016-10-26 12:47
Analysis date: 2016-10-26 12:47
M1032 XRayHRQualification
Summary
| Module | Module | M1032 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 159 | |
| BumpBondingDefects | Bump Bonding Defects | 157 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 1 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 150/300 | 99.82/99.31 | % |
| Noise | Mean Noise | 326 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.84 | 99.58 | 0.26 | 81.0 | 256.6 | 0 | 0/0 | 0 | 3760 | 342 | 985 |
|
Chip 1
|
A
|
0 | 0 | 99.84 | 99.61 | 0.26 | 68.1 | 211.4 | 0 | 0/0 | 0 | 3803 | 327 | 787 |
|
Chip 2
|
A
|
0 | 0 | 99.81 | 99.56 | 0.34 | 75.6 | 229.8 | 0 | 0/0 | 0 | 3749 | 360 | 1215 |
|
Chip 3
|
A
|
0 | 0 | 99.79 | 99.55 | 0.26 | 55.3 | 167.7 | 0 | 0/0 | 0 | 3554 | 331 | 819 |
|
Chip 4
|
A
|
0 | 0 | 99.82 | 99.63 | 0.23 | 43.2 | 130.6 | 0 | 0/0 | 0 | 3844 | 308 | 495 |
|
Chip 5
|
A
|
0 | 0 | 99.84 | 99.53 | 0.29 | 51.9 | 158.0 | 0 | 0/0 | 0 | 3855 | 312 | 550 |
|
Chip 6
|
A
|
0 | 0 | 99.80 | 99.62 | 0.27 | 43.4 | 133.8 | 0 | 0/0 | 0 | 3838 | 302 | 373 |
|
Chip 7
|
A
|
1 | 0 | 99.82 | 99.34 | 0.26 | 44.1 | 135.2 | 0 | 0/0 | 0 | 3852 | 286 | 272 |
|
Chip 8
|
A
|
0 | 0 | 99.82 | 99.44 | 0.22 | 45.5 | 139.5 | 0 | 0/0 | 0 | 3807 | 303 | 466 |
|
Chip 9
|
C
|
158 | 0 | 99.80 | 95.74 | 146.53 | 45.5 | 138.6 | 159 | 0/0 | 2 | 3767 | 319 | 608 |
|
Chip 10
|
A
|
0 | 0 | 99.83 | 99.62 | 0.29 | 66.1 | 206.4 | 0 | 0/0 | 0 | 3736 | 366 | 1340 |
|
Chip 11
|
A
|
0 | 0 | 99.80 | 99.56 | 0.26 | 39.9 | 121.0 | 0 | 0/0 | 0 | 3865 | 281 | 242 |
|
Chip 12
|
A
|
0 | 0 | 99.81 | 99.47 | 0.23 | 44.8 | 136.1 | 0 | 0/0 | 0 | 3819 | 301 | 478 |
|
Chip 13
|
A
|
0 | 0 | 99.81 | 99.57 | 0.3 | 74.0 | 231.6 | 0 | 0/0 | 0 | 3724 | 362 | 1254 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 99.56 | 0.37 | 77.6 | 239.1 | 0 | 0/0 | 0 | 3637 | 344 | 1038 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 99.60 | 0.27 | 85.8 | 271.8 | 0 | 0/0 | 0 | 3767 | 370 | 1387 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-26 | |
| TestTime | Test Time | 11:39 | |
| TestDuration | Duration | 0:58:19 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
