Test Date: 2016-10-26 11:39
Analysis date: 2016-10-26 12:45
Analysis date: 2016-10-26 12:45
M1030 XRayHRQualification
Summary
| Module | Module | M1030 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 16 | |
| BumpBondingDefects | Bump Bonding Defects | 16 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.57 | % |
| Noise | Mean Noise | 330 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.82 | 99.56 | 0.32 | 68.6 | 205.4 | 0 | 0/0 | 0 | 3522 | 326 | 730 |
|
Chip 1
|
A
|
1 | 0 | 99.82 | 99.55 | 0.29 | 67.8 | 203.1 | 1 | 0/0 | 0 | 3780 | 332 | 839 |
|
Chip 2
|
A
|
0 | 0 | 99.84 | 99.56 | 0.3 | 72.7 | 218.8 | 0 | 0/0 | 0 | 3784 | 325 | 707 |
|
Chip 3
|
A
|
14 | 0 | 99.82 | 99.61 | 0.34 | 53.2 | 156.8 | 15 | 0/0 | 0 | 3870 | 298 | 384 |
|
Chip 4
|
A
|
0 | 0 | 99.82 | 99.58 | 0.28 | 62.8 | 188.8 | 0 | 0/0 | 0 | 3773 | 333 | 854 |
|
Chip 5
|
A
|
0 | 0 | 99.83 | 99.56 | 0.38 | 80.4 | 242.6 | 0 | 0/0 | 0 | 3778 | 356 | 1210 |
|
Chip 6
|
A
|
1 | 0 | 99.81 | 99.55 | 0.36 | 84.3 | 252.5 | 1 | 0/0 | 0 | 3749 | 345 | 1042 |
|
Chip 7
|
A
|
0 | 0 | 99.83 | 99.56 | 0.32 | 88.9 | 269.6 | 0 | 0/0 | 0 | 3740 | 351 | 1150 |
|
Chip 8
|
A
|
0 | 0 | 99.83 | 99.59 | 0.36 | 83.5 | 252.0 | 0 | 0/0 | 0 | 3775 | 368 | 1389 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.58 | 0.32 | 78.6 | 239.8 | 0 | 0/0 | 0 | 3778 | 342 | 1022 |
|
Chip 10
|
A
|
0 | 0 | 99.83 | 99.57 | 0.36 | 69.1 | 209.6 | 0 | 0/0 | 0 | 3766 | 335 | 866 |
|
Chip 11
|
A
|
0 | 0 | 99.81 | 99.56 | 0.2 | 52.8 | 158.7 | 0 | 0/0 | 0 | 3829 | 331 | 794 |
|
Chip 12
|
A
|
0 | 0 | 99.82 | 99.58 | 0.29 | 48.7 | 147.9 | 0 | 0/0 | 0 | 3616 | 304 | 513 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 99.54 | 0.37 | 71.3 | 214.9 | 0 | 0/0 | 0 | 3786 | 328 | 806 |
|
Chip 14
|
A
|
0 | 0 | 99.83 | 99.52 | 0.39 | 53.2 | 158.9 | 0 | 0/0 | 0 | 3858 | 292 | 306 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 99.58 | 0.3 | 64.7 | 195.9 | 0 | 0/0 | 0 | 3816 | 316 | 655 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-26 | |
| TestTime | Test Time | 11:39 | |
| TestDuration | Duration | 0:58:19 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-11-g3f3decf on branch master
