Test Date: 2016-10-25 14:33
Analysis date: 2016-10-26 10:19
Analysis date: 2016-10-26 10:19
M1029 XRayHRQualification
Summary
| Module | Module | M1029 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 158 | |
| BumpBondingDefects | Bump Bonding Defects | 157 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 1 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 150/300 | 99.82/99.61 | % |
| Noise | Mean Noise | 296 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.82 | 99.58 | 0.29 | 61.3 | 188.9 | 0 | 0/0 | 0 | 3771 | 331 | 768 |
|
Chip 1
|
A
|
0 | 0 | 99.80 | 99.55 | 0.27 | 64.0 | 196.7 | 0 | 0/0 | 0 | 3775 | 327 | 696 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.56 | 0.29 | 61.0 | 187.8 | 0 | 0/0 | 0 | 3819 | 336 | 812 |
|
Chip 3
|
A
|
0 | 0 | 99.83 | 99.54 | 0.31 | 52.4 | 160.4 | 0 | 0/0 | 0 | 3890 | 287 | 328 |
|
Chip 4
|
C
|
158 | 0 | 99.83 | 99.41 | 0.17 | 51.3 | 154.1 | 159 | 0/0 | 2 | 3854 | 269 | 181 |
|
Chip 5
|
A
|
0 | 0 | 99.80 | 99.56 | 0.22 | 78.7 | 241.0 | 0 | 0/0 | 0 | 3808 | 293 | 370 |
|
Chip 6
|
A
|
0 | 0 | 99.78 | 99.75 | 1.2 | 73.8 | 224.6 | 0 | 0/0 | 0 | 3836 | 306 | 457 |
|
Chip 7
|
A
|
0 | 0 | 99.82 | 99.61 | 0.18 | 76.2 | 232.4 | 0 | 0/0 | 0 | 3942 | 276 | 176 |
|
Chip 8
|
A
|
0 | 0 | 99.82 | 100.77 | 0.18 | 70.9 | 217.7 | 0 | 0/0 | 0 | 3911 | 275 | 199 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.87 | 0.27 | 71.3 | 217.8 | 0 | 0/0 | 0 | 3915 | 304 | 392 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.13 | 0.15 | 59.3 | 182.7 | 0 | 0/0 | 0 | 3914 | 275 | 185 |
|
Chip 11
|
A
|
0 | 0 | 99.84 | 99.16 | 0.24 | 32.4 | 99.8 | 0 | 0/0 | 0 | 4048 | 223 | 41 |
|
Chip 12
|
A
|
0 | 0 | 99.82 | 99.58 | 0.19 | 43.4 | 132.0 | 0 | 0/0 | 0 | 3923 | 271 | 191 |
|
Chip 13
|
A
|
0 | 0 | 99.81 | 99.62 | 0.26 | 61.4 | 187.8 | 0 | 0/0 | 0 | 3862 | 310 | 509 |
|
Chip 14
|
A
|
0 | 0 | 99.81 | 99.54 | 0.26 | 52.8 | 162.8 | 0 | 0/0 | 0 | 3849 | 336 | 832 |
|
Chip 15
|
A
|
0 | 0 | 99.81 | 99.60 | 0.3 | 54.7 | 167.7 | 0 | 0/0 | 0 | 3828 | 320 | 580 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-25 | |
| TestTime | Test Time | 14:33 | |
| TestDuration | Duration | 0:58:57 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 20 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
