Test Date: 2016-10-25 14:33
Analysis date: 2016-10-26 11:39
Analysis date: 2016-10-26 11:39
M1027 XRayHRQualification
Summary
| Module | Module | M1027 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 6 | |
| BumpBondingDefects | Bump Bonding Defects | 6 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.56 | % |
| Noise | Mean Noise | 327 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
2 | 0 | 99.81 | 99.47 | 0.44 | 74.5 | 223.0 | 2 | 0/0 | 0 | 3837 | 317 | 646 |
|
Chip 1
|
A
|
1 | 0 | 99.82 | 99.63 | 0.28 | 69.3 | 208.4 | 1 | 0/0 | 0 | 3810 | 312 | 587 |
|
Chip 2
|
A
|
1 | 0 | 99.80 | 99.37 | 0.28 | 65.0 | 196.2 | 1 | 0/0 | 0 | 3780 | 321 | 693 |
|
Chip 3
|
A
|
1 | 0 | 99.79 | 99.57 | 0.37 | 57.5 | 172.6 | 1 | 0/0 | 0 | 3814 | 320 | 688 |
|
Chip 4
|
A
|
0 | 0 | 99.80 | 99.58 | 0.25 | 60.0 | 184.6 | 0 | 0/0 | 0 | 3791 | 339 | 945 |
|
Chip 5
|
A
|
0 | 0 | 99.83 | 99.58 | 0.25 | 78.5 | 235.3 | 0 | 0/0 | 0 | 3756 | 340 | 962 |
|
Chip 6
|
A
|
0 | 0 | 99.80 | 99.56 | 0.3 | 81.1 | 242.9 | 0 | 0/0 | 0 | 3763 | 347 | 1039 |
|
Chip 7
|
A
|
0 | 0 | 99.81 | 99.53 | 0.32 | 89.6 | 270.0 | 0 | 0/0 | 0 | 3798 | 349 | 1089 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.55 | 0.37 | 84.8 | 258.5 | 0 | 0/0 | 0 | 3765 | 345 | 1050 |
|
Chip 9
|
A
|
0 | 0 | 99.83 | 99.56 | 0.3 | 79.9 | 241.8 | 0 | 0/0 | 0 | 3757 | 325 | 742 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.51 | 0.32 | 77.1 | 235.8 | 0 | 0/0 | 0 | 3799 | 342 | 1005 |
|
Chip 11
|
A
|
1 | 0 | 99.82 | 99.63 | 0.26 | 54.3 | 163.6 | 1 | 0/0 | 0 | 3773 | 327 | 767 |
|
Chip 12
|
A
|
0 | 0 | 99.80 | 99.54 | 0.22 | 56.2 | 169.7 | 0 | 0/0 | 0 | 3790 | 329 | 723 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 99.63 | 0.25 | 64.5 | 194.0 | 0 | 0/0 | 0 | 3568 | 309 | 520 |
|
Chip 14
|
A
|
0 | 0 | 99.83 | 99.42 | 0.21 | 66.1 | 196.9 | 0 | 0/0 | 0 | 3787 | 317 | 629 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 99.91 | 0.25 | 55.3 | 168.6 | 0 | 0/0 | 0 | 3847 | 290 | 305 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-25 | |
| TestTime | Test Time | 14:33 | |
| TestDuration | Duration | 0:58:57 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 13 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-11-g3f3decf on branch master
