Test Date: 2016-10-25 12:40
Analysis date: 2016-10-25 21:04
Analysis date: 2016-10-25 21:04
M1026 XRayHRQualification
Summary
| Module | Module | M1026 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.62 | % |
| Noise | Mean Noise | 300 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.83 | 99.54 | 0.32 | 67.1 | 203.4 | 0 | 0/0 | 0 | 3793 | 328 | 769 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.60 | 0.3 | 67.3 | 204.9 | 0 | 0/0 | 0 | 3824 | 329 | 774 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.60 | 0.2 | 55.7 | 169.6 | 0 | 0/0 | 0 | 3901 | 292 | 287 |
|
Chip 3
|
A
|
0 | 0 | 99.82 | 99.70 | 0.17 | 47.0 | 141.8 | 0 | 0/0 | 0 | 3916 | 274 | 218 |
|
Chip 4
|
A
|
0 | 0 | 99.81 | 99.63 | 0.26 | 58.3 | 177.2 | 0 | 0/0 | 0 | 3889 | 308 | 512 |
|
Chip 5
|
A
|
0 | 0 | 99.84 | 99.65 | 0.13 | 70.9 | 216.7 | 0 | 0/0 | 0 | 3885 | 300 | 410 |
|
Chip 6
|
A
|
0 | 0 | 99.75 | 99.85 | 0.24 | 71.0 | 215.7 | 0 | 0/0 | 0 | 3933 | 283 | 213 |
|
Chip 7
|
A
|
0 | 0 | 99.84 | 99.82 | 0.19 | 69.3 | 209.9 | 0 | 0/0 | 0 | 3971 | 272 | 174 |
|
Chip 8
|
A
|
0 | 0 | 99.83 | 99.45 | 0.18 | 94.2 | 290.4 | 0 | 0/0 | 0 | 3914 | 301 | 410 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.42 | 0.25 | 73.4 | 224.2 | 0 | 0/0 | 0 | 3949 | 285 | 252 |
|
Chip 10
|
A
|
0 | 0 | 99.81 | 99.71 | 0.25 | 86.8 | 263.4 | 0 | 0/0 | 0 | 3873 | 314 | 525 |
|
Chip 11
|
A
|
0 | 0 | 99.83 | 99.65 | 0.16 | 59.5 | 183.8 | 0 | 0/0 | 0 | 3917 | 290 | 334 |
|
Chip 12
|
A
|
0 | 0 | 99.84 | 99.67 | 0.21 | 48.7 | 148.1 | 0 | 0/0 | 0 | 3911 | 280 | 266 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 99.55 | 0.26 | 63.5 | 193.9 | 0 | 0/0 | 0 | 3848 | 308 | 500 |
|
Chip 14
|
A
|
1 | 0 | 99.83 | 99.55 | 0.25 | 70.5 | 214.8 | 1 | 0/0 | 0 | 3851 | 308 | 549 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 99.56 | 0.39 | 73.2 | 224.0 | 0 | 0/0 | 0 | 3817 | 323 | 725 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-25 | |
| TestTime | Test Time | 12:40 | |
| TestDuration | Duration | 0:59:48 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 20 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
