Test Date: 2016-10-25 11:19
Analysis date: 2016-10-25 12:41
Analysis date: 2016-10-25 12:41
M1023 XRayHRQualification
Summary
| Module | Module | M1023 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 0 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.55 | % |
| Noise | Mean Noise | 332 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.82 | 99.49 | 0.17 | 61.5 | 186.3 | 0 | 0/0 | 0 | 3932 | 321 | 672 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.63 | 0.38 | 64.5 | 197.0 | 0 | 0/0 | 0 | 3805 | 320 | 679 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.57 | 0.36 | 82.8 | 247.9 | 0 | 0/0 | 0 | 3712 | 378 | 1473 |
|
Chip 3
|
A
|
0 | 0 | 99.81 | 99.58 | 0.32 | 51.6 | 155.3 | 0 | 0/0 | 0 | 3800 | 326 | 747 |
|
Chip 4
|
A
|
0 | 0 | 99.83 | 99.53 | 0.24 | 56.5 | 170.3 | 0 | 0/0 | 0 | 3727 | 327 | 727 |
|
Chip 5
|
A
|
0 | 0 | 99.84 | 99.58 | 0.37 | 74.8 | 227.5 | 0 | 0/0 | 0 | 3724 | 338 | 924 |
|
Chip 6
|
A
|
0 | 0 | 99.83 | 99.58 | 0.25 | 77.4 | 234.4 | 0 | 0/0 | 0 | 3761 | 343 | 997 |
|
Chip 7
|
A
|
0 | 0 | 99.83 | 99.59 | 0.37 | 86.3 | 263.8 | 0 | 0/0 | 0 | 3800 | 343 | 1071 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.54 | 0.34 | 70.4 | 211.4 | 0 | 0/0 | 0 | 3850 | 312 | 580 |
|
Chip 9
|
A
|
0 | 0 | 99.83 | 99.55 | 0.38 | 85.9 | 262.5 | 0 | 0/0 | 0 | 3764 | 354 | 1141 |
|
Chip 10
|
A
|
0 | 0 | 99.83 | 99.59 | 0.38 | 80.6 | 244.2 | 0 | 0/0 | 0 | 3727 | 351 | 1077 |
|
Chip 11
|
A
|
0 | 0 | 99.81 | 99.62 | 0.19 | 54.6 | 164.6 | 0 | 0/0 | 0 | 3581 | 317 | 616 |
|
Chip 12
|
A
|
0 | 0 | 99.81 | 99.55 | 0.24 | 57.7 | 177.5 | 0 | 0/0 | 0 | 3494 | 342 | 1004 |
|
Chip 13
|
A
|
0 | 0 | 99.81 | 99.58 | 0.3 | 73.5 | 221.3 | 0 | 0/0 | 0 | 3548 | 308 | 566 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 99.46 | 0.29 | 63.8 | 191.5 | 0 | 0/0 | 0 | 3813 | 326 | 765 |
|
Chip 15
|
A
|
0 | 0 | 99.81 | 99.44 | 0.2 | 59.7 | 181.0 | 0 | 0/0 | 0 | 3818 | 308 | 511 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-25 | |
| TestTime | Test Time | 11:19 | |
| TestDuration | Duration | 0:56:41 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
