Test Date: 2016-10-25 09:48
Analysis date: 2016-10-25 10:56
Analysis date: 2016-10-25 10:56
M1018 XRayHRQualification
Summary
| Module | Module | M1018 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 4 | |
| BumpBondingDefects | Bump Bonding Defects | 2 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 1 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 150/300 | 99.81/99.51 | % |
| Noise | Mean Noise | 321 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.81 | 99.40 | 0.31 | 58.0 | 177.0 | 0 | 0/0 | 0 | 3538 | 336 | 868 |
|
Chip 1
|
A
|
1 | 0 | 99.82 | 99.35 | 0.25 | 47.2 | 144.2 | 1 | 0/0 | 0 | 3887 | 292 | 319 |
|
Chip 2
|
A
|
0 | 0 | 99.80 | 99.59 | 0.22 | 68.8 | 207.9 | 0 | 0/0 | 0 | 3788 | 322 | 737 |
|
Chip 3
|
A
|
0 | 0 | 99.81 | 99.55 | 0.37 | 56.7 | 172.4 | 0 | 0/0 | 0 | 3826 | 323 | 730 |
|
Chip 4
|
C
|
2 | 0 | 99.82 | 99.48 | 0.32 | 46.6 | 141.4 | 1 | 0/0 | 1+10/141 | 3864 | 298 | 365 |
|
Chip 5
|
A
|
0 | 0 | 99.82 | 99.57 | 0.23 | 62.8 | 196.1 | 0 | 0/0 | 0 | 3831 | 316 | 610 |
|
Chip 6
|
A
|
0 | 0 | 99.79 | 99.48 | 0.5 | 82.2 | 251.7 | 0 | 0/0 | 0 | 3765 | 339 | 1017 |
|
Chip 7
|
A
|
0 | 0 | 99.81 | 99.54 | 0.42 | 85.2 | 269.4 | 0 | 0/0 | 0 | 3766 | 348 | 1080 |
|
Chip 8
|
A
|
0 | 0 | 99.82 | 99.48 | 0.4 | 71.4 | 222.8 | 0 | 0/0 | 0 | 3833 | 310 | 574 |
|
Chip 9
|
A
|
0 | 0 | 99.81 | 99.51 | 0.42 | 73.1 | 225.0 | 0 | 0/0 | 0 | 3802 | 319 | 684 |
|
Chip 10
|
A
|
0 | 0 | 99.83 | 99.56 | 0.38 | 78.8 | 249.6 | 0 | 0/0 | 0 | 3711 | 344 | 1007 |
|
Chip 11
|
A
|
0 | 0 | 99.82 | 99.53 | 0.5 | 48.3 | 147.6 | 0 | 0/0 | 0 | 3866 | 306 | 472 |
|
Chip 12
|
A
|
1 | 0 | 99.77 | 99.46 | 0.27 | 50.9 | 154.6 | 0 | 0/0 | 0 | 3833 | 318 | 597 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 99.57 | 0.25 | 64.5 | 199.0 | 0 | 0/0 | 0 | 3797 | 313 | 587 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 99.51 | 0.34 | 63.0 | 193.6 | 0 | 0/0 | 0 | 3733 | 333 | 840 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 99.57 | 0.35 | 63.6 | 196.9 | 0 | 0/0 | 0 | 3850 | 316 | 645 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-25 | |
| TestTime | Test Time | 09:48 | |
| TestDuration | Duration | 1:0:13 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 159430 | |
| nWarnings | # Warnings | 105055 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 3 | |
| channel_2_count | Channel 2 | 27 | |
| channel_3_count | Channel 3 | 17 | |
| message_eventid_count | Event ID mismatch | 50630 | |
| message_notokenpass_count | has NoTokenPass | 689 | |
| message_tokenchain_count | Token Chain Length | 11525 | |
| message_readback_count | Readback start marker | 4048 |
MoReWeb-v1.0.5-11-g3f3decf on branch master
