M1017 XRayHRQualification
Summary
| Module | Module | M1017 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 40 | |
| BumpBondingDefects | Bump Bonding Defects | 36 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 2 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.53 | % |
| Noise | Mean Noise | 304 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.84 | 99.56 | 0.28 | 58.8 | 176.8 | 0 | 0/0 | 0 | 3907 | 297 | 429 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.58 | 0.36 | 67.3 | 205.1 | 0 | 0/0 | 0 | 3784 | 327 | 798 |
|
Chip 2
|
A
|
2 | 0 | 99.78 | 99.49 | 0.34 | 69.7 | 212.1 | 0 | 0/0 | 0 | 3778 | 325 | 757 |
|
Chip 3
|
A
|
0 | 0 | 99.80 | 99.48 | 0.31 | 52.4 | 161.0 | 0 | 0/0 | 0 | 3863 | 310 | 524 |
|
Chip 4
|
A
|
0 | 0 | 99.78 | 99.42 | 0.66 | 49.6 | 150.0 | 0 | 0/0 | 0 | 3947 | 275 | 242 |
|
Chip 5
|
A
|
3 | 0 | 99.80 | 99.54 | 0.28 | 71.3 | 217.6 | 1 | 0/0 | 0 | 3586 | 300 | 400 |
|
Chip 6
|
A
|
0 | 0 | 99.80 | 99.43 | 0.26 | 68.3 | 208.3 | 0 | 0/0 | 0 | 3685 | 283 | 212 |
|
Chip 7
|
A
|
0 | 0 | 99.82 | 99.60 | 0.22 | 85.5 | 267.1 | 0 | 0/0 | 0 | 3637 | 306 | 446 |
|
Chip 8
|
A
|
0 | 0 | 99.82 | 99.65 | 0.18 | 76.2 | 234.9 | 0 | 0/0 | 0 | 3947 | 290 | 273 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.50 | 0.2 | 82.0 | 256.3 | 0 | 0/0 | 0 | 3820 | 322 | 689 |
|
Chip 10
|
A
|
0 | 0 | 99.83 | 99.47 | 0.2 | 74.2 | 231.9 | 0 | 0/0 | 0 | 3861 | 312 | 485 |
|
Chip 11
|
A
|
4 | 0 | 99.82 | 99.52 | 0.22 | 52.4 | 160.5 | 4 | 0/0 | 0 | 3890 | 293 | 353 |
|
Chip 12
|
A
|
1 | 0 | 99.79 | 99.57 | 0.28 | 42.2 | 128.3 | 1 | 0/0 | 0 | 3933 | 255 | 121 |
|
Chip 13
|
A
|
0 | 0 | 99.81 | 99.53 | 0.35 | 60.6 | 185.4 | 0 | 0/0 | 0 | 3873 | 298 | 376 |
|
Chip 14
|
A
|
0 | 0 | 99.79 | 99.53 | 0.36 | 66.5 | 205.8 | 0 | 0/0 | 0 | 3492 | 361 | 1221 |
|
Chip 15
|
A
|
30 | 0 | 99.83 | 99.57 | 0.22 | 54.4 | 167.2 | 32 | 0/0 | 0 | 3866 | 309 | 500 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-25 | |
| TestTime | Test Time | 08:21 | |
| TestDuration | Duration | 0:57:22 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
