Test Date: 2016-10-24 19:10
Analysis date: 2016-10-25 09:37
Analysis date: 2016-10-25 09:37
M1015 XRayHRQualification
Summary
| Module | Module | M1015 | |
| Grade | Grade | B | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/1/0 | |
| PixelDefects | Total Pixel Defects | 55 | |
| BumpBondingDefects | Bump Bonding Defects | 55 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.51 | % |
| Noise | Mean Noise | 302 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
2 | 0 | 99.81 | 99.52 | 0.35 | 72.6 | 219.3 | 4 | 0/0 | 0 | 3542 | 319 | 710 |
|
Chip 1
|
A
|
1 | 0 | 99.81 | 99.49 | 0.47 | 64.4 | 194.3 | 1 | 0/0 | 0 | 3765 | 320 | 670 |
|
Chip 2
|
A
|
1 | 0 | 99.80 | 99.55 | 0.32 | 58.7 | 177.3 | 1 | 0/0 | 0 | 3855 | 300 | 414 |
|
Chip 3
|
A
|
1 | 0 | 99.80 | 99.59 | 0.22 | 53.2 | 161.1 | 1 | 0/0 | 0 | 3671 | 293 | 392 |
|
Chip 4
|
A
|
0 | 0 | 99.81 | 99.53 | 0.24 | 54.5 | 166.1 | 0 | 0/0 | 0 | 3895 | 314 | 571 |
|
Chip 5
|
A
|
0 | 0 | 99.82 | 99.51 | 0.3 | 78.2 | 237.3 | 0 | 0/0 | 0 | 3848 | 304 | 435 |
|
Chip 6
|
A
|
0 | 0 | 99.82 | 99.53 | 0.2 | 80.8 | 243.6 | 0 | 0/0 | 0 | 3846 | 312 | 513 |
|
Chip 7
|
A
|
0 | 0 | 99.79 | 99.54 | 0.24 | 94.4 | 283.7 | 0 | 0/0 | 0 | 3849 | 326 | 703 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.42 | 0.23 | 95.1 | 291.1 | 0 | 0/0 | 0 | 3880 | 299 | 369 |
|
Chip 9
|
A
|
0 | 0 | 99.81 | 99.27 | 0.22 | 60.2 | 183.3 | 0 | 0/0 | 0 | 3926 | 260 | 110 |
|
Chip 10
|
A
|
0 | 0 | 99.79 | 99.48 | 0.29 | 66.6 | 201.8 | 0 | 0/0 | 0 | 3890 | 289 | 273 |
|
Chip 11
|
A
|
0 | 0 | 99.81 | 99.61 | 0.27 | 53.2 | 161.7 | 0 | 0/0 | 0 | 3904 | 303 | 391 |
|
Chip 12
|
A
|
0 | 0 | 99.79 | 99.54 | 0.26 | 43.6 | 132.0 | 0 | 0/0 | 0 | 3890 | 277 | 266 |
|
Chip 13
|
A
|
0 | 0 | 99.81 | 99.58 | 0.23 | 59.8 | 181.9 | 0 | 0/0 | 0 | 3859 | 314 | 533 |
|
Chip 14
|
A
|
2 | 0 | 99.81 | 99.52 | 0.39 | 63.7 | 193.9 | 3 | 0/0 | 0 | 3823 | 292 | 336 |
|
Chip 15
|
B
|
48 | 0 | 99.80 | 99.51 | 0.36 | 66.8 | 201.8 | 53 | 0/0 | 0 | 3601 | 316 | 611 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-24 | |
| TestTime | Test Time | 19:10 | |
| TestDuration | Duration | 0:56:33 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 15 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
