Test Date: 2016-10-24 19:10
Analysis date: 2016-10-24 21:07
Analysis date: 2016-10-24 21:07
M1014 XRayHRQualification
Summary
| Module | Module | M1014 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 4 | |
| BumpBondingDefects | Bump Bonding Defects | 4 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.57 | % |
| Noise | Mean Noise | 312 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.83 | 99.54 | 0.33 | 64.8 | 198.0 | 0 | 0/0 | 0 | 3845 | 318 | 625 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 99.58 | 0.36 | 61.5 | 187.2 | 0 | 0/0 | 0 | 3835 | 302 | 458 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.63 | 0.22 | 57.7 | 179.5 | 0 | 0/0 | 0 | 3862 | 287 | 329 |
|
Chip 3
|
A
|
0 | 0 | 99.83 | 99.59 | 0.24 | 50.3 | 152.9 | 0 | 0/0 | 0 | 3619 | 295 | 383 |
|
Chip 4
|
A
|
0 | 0 | 99.79 | 99.49 | 0.29 | 48.8 | 147.3 | 0 | 0/0 | 0 | 3886 | 280 | 248 |
|
Chip 5
|
A
|
0 | 0 | 99.85 | 99.60 | 0.34 | 78.7 | 246.2 | 0 | 0/0 | 0 | 3821 | 318 | 665 |
|
Chip 6
|
A
|
0 | 0 | 99.80 | 99.52 | 0.29 | 70.0 | 216.7 | 0 | 0/0 | 0 | 3837 | 323 | 725 |
|
Chip 7
|
A
|
0 | 0 | 99.82 | 99.55 | 0.26 | 76.0 | 234.5 | 0 | 0/0 | 0 | 3784 | 334 | 893 |
|
Chip 8
|
A
|
0 | 0 | 99.82 | 99.57 | 0.36 | 78.6 | 241.0 | 0 | 0/0 | 0 | 3807 | 325 | 747 |
|
Chip 9
|
A
|
0 | 0 | 99.83 | 99.60 | 0.31 | 70.5 | 220.8 | 0 | 0/0 | 0 | 3792 | 321 | 694 |
|
Chip 10
|
A
|
0 | 0 | 99.84 | 99.56 | 0.28 | 81.1 | 251.2 | 0 | 0/0 | 0 | 3720 | 341 | 1015 |
|
Chip 11
|
A
|
1 | 0 | 99.82 | 99.57 | 0.22 | 59.8 | 181.5 | 1 | 0/0 | 0 | 3609 | 313 | 574 |
|
Chip 12
|
A
|
1 | 0 | 99.83 | 99.60 | 0.2 | 52.5 | 162.3 | 1 | 0/0 | 0 | 3809 | 302 | 463 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 99.56 | 0.26 | 70.7 | 217.7 | 0 | 0/0 | 0 | 3740 | 330 | 838 |
|
Chip 14
|
A
|
1 | 0 | 99.82 | 99.56 | 0.28 | 71.6 | 220.6 | 1 | 0/0 | 0 | 3800 | 320 | 703 |
|
Chip 15
|
A
|
1 | 0 | 99.83 | 99.57 | 0.39 | 63.6 | 195.9 | 1 | 0/0 | 0 | 3618 | 289 | 347 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-24 | |
| TestTime | Test Time | 19:10 | |
| TestDuration | Duration | 0:56:33 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-11-g3f3decf on branch master
