Test Date: 2016-10-24 17:03
Analysis date: 2016-10-24 21:22
Analysis date: 2016-10-24 21:22
M1013 XRayHRQualification
Summary
| Module | Module | M1013 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 35 | |
| BumpBondingDefects | Bump Bonding Defects | 35 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.58 | % |
| Noise | Mean Noise | 340 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.78 | 99.51 | 0.32 | 68.8 | 218.2 | 0 | 0/0 | 0 | 3548 | 347 | 1056 |
|
Chip 1
|
A
|
2 | 0 | 99.81 | 99.53 | 0.36 | 78.0 | 243.0 | 3 | 0/0 | 0 | 3807 | 329 | 785 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.51 | 0.34 | 68.6 | 212.7 | 2 | 0/0 | 0 | 3746 | 352 | 1100 |
|
Chip 3
|
A
|
0 | 0 | 99.83 | 99.57 | 0.23 | 47.8 | 147.4 | 0 | 0/0 | 0 | 3852 | 327 | 736 |
|
Chip 4
|
A
|
0 | 0 | 99.81 | 99.63 | 0.16 | 42.1 | 128.8 | 0 | 0/0 | 0 | 3874 | 313 | 581 |
|
Chip 5
|
A
|
0 | 0 | 99.80 | 99.53 | 0.24 | 55.9 | 172.3 | 0 | 0/0 | 0 | 3772 | 364 | 1292 |
|
Chip 6
|
A
|
0 | 0 | 99.81 | 99.53 | 0.27 | 44.9 | 138.7 | 0 | 0/0 | 0 | 3842 | 332 | 756 |
|
Chip 7
|
A
|
0 | 0 | 99.81 | 99.78 | 0.24 | 44.1 | 137.1 | 0 | 0/0 | 0 | 3866 | 322 | 619 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.62 | 0.23 | 42.0 | 130.7 | 0 | 0/0 | 0 | 3887 | 322 | 681 |
|
Chip 9
|
A
|
0 | 0 | 99.77 | 99.55 | 0.29 | 49.2 | 150.8 | 0 | 0/0 | 0 | 3849 | 327 | 721 |
|
Chip 10
|
A
|
0 | 0 | 99.83 | 99.59 | 0.28 | 59.8 | 184.3 | 0 | 0/0 | 0 | 3751 | 332 | 871 |
|
Chip 11
|
A
|
0 | 0 | 99.78 | 99.72 | 0.26 | 38.5 | 116.9 | 1 | 0/0 | 0 | 3888 | 317 | 574 |
|
Chip 12
|
A
|
6 | 0 | 99.82 | 99.61 | 0.24 | 50.0 | 152.6 | 10 | 0/0 | 0 | 3725 | 382 | 1536 |
|
Chip 13
|
A
|
27 | 0 | 99.79 | 99.51 | 0.29 | 67.0 | 205.6 | 27 | 0/0 | 0 | 3555 | 387 | 1594 |
|
Chip 14
|
A
|
0 | 0 | 99.81 | 99.50 | 0.26 | 64.6 | 201.6 | 0 | 0/0 | 0 | 3793 | 343 | 987 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 99.57 | 0.31 | 66.7 | 210.7 | 0 | 0/0 | 0 | 3809 | 341 | 915 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-24 | |
| TestTime | Test Time | 17:03 | |
| TestDuration | Duration | 1:0:2 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-11-g3f3decf on branch master
