Test Date: 2016-10-24 16:23
Analysis date: 2016-10-24 20:40
Analysis date: 2016-10-24 20:40
M1010 XRayHRQualification
Summary
| Module | Module | M1010 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 75 | |
| BumpBondingDefects | Bump Bonding Defects | 73 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.80/99.53 | % |
| Noise | Mean Noise | 322 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.81 | 99.53 | 0.31 | 201.1 | 0 | 67.2 | 0/0 | 0 | 3765 | 350 | 1110 |
|
Chip 1
|
A
|
0 | 0 | 99.79 | 99.49 | 0.35 | 200.2 | 1 | 66.7 | 0/0 | 0 | 3752 | 337 | 933 |
|
Chip 2
|
A
|
1 | 0 | 99.81 | 99.55 | 0.36 | 238.6 | 0 | 80.0 | 0/0 | 0 | 3628 | 342 | 1010 |
|
Chip 3
|
A
|
0 | 0 | 99.81 | 99.52 | 0.27 | 160.2 | 0 | 53.1 | 0/0 | 0 | 3844 | 321 | 646 |
|
Chip 4
|
A
|
0 | 0 | 99.78 | 99.55 | 0.98 | 188.3 | 0 | 63.2 | 0/0 | 0 | 3867 | 321 | 647 |
|
Chip 5
|
A
|
0 | 0 | 99.78 | 99.54 | 0.26 | 246.6 | 0 | 82.1 | 0/0 | 0 | 3821 | 324 | 698 |
|
Chip 6
|
A
|
1 | 0 | 99.82 | 99.50 | 0.25 | 247.2 | 0 | 81.8 | 0/0 | 0 | 3842 | 324 | 678 |
|
Chip 7
|
A
|
0 | 0 | 99.79 | 99.60 | 0.17 | 263.7 | 0 | 87.7 | 0/0 | 0 | 3880 | 322 | 656 |
|
Chip 8
|
A
|
0 | 0 | 99.83 | 99.40 | 0.22 | 254.4 | 0 | 84.9 | 0/0 | 0 | 3911 | 295 | 336 |
|
Chip 9
|
A
|
0 | 0 | 99.81 | 99.45 | 0.18 | 275.1 | 0 | 91.5 | 0/0 | 0 | 3623 | 321 | 671 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.56 | 0.26 | 236.8 | 0 | 78.0 | 0/0 | 0 | 3875 | 305 | 441 |
|
Chip 11
|
A
|
9 | 0 | 99.79 | 99.55 | 0.28 | 188.9 | 13 | 63.0 | 0/0 | 0 | 3711 | 302 | 470 |
|
Chip 12
|
A
|
36 | 0 | 99.82 | 99.56 | 0.31 | 161.2 | 38 | 53.3 | 0/0 | 0 | 3801 | 321 | 650 |
|
Chip 13
|
A
|
23 | 0 | 99.79 | 99.52 | 0.31 | 216.2 | 28 | 72.5 | 0/0 | 0 | 3806 | 322 | 667 |
|
Chip 14
|
A
|
0 | 0 | 99.80 | 99.57 | 0.3 | 203.2 | 0 | 67.0 | 0/0 | 0 | 3801 | 333 | 790 |
|
Chip 15
|
A
|
5 | 0 | 99.80 | 99.54 | 0.36 | 191.4 | 6 | 63.0 | 0/0 | 0 | 3813 | 303 | 454 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-24 | |
| TestTime | Test Time | 16:23 | |
| TestDuration | Duration | 0:36:34 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 20 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
