Test Date: 2016-10-24 15:14
Analysis date: 2016-10-24 20:25
Analysis date: 2016-10-24 20:25
M1009 XRayHRQualification
| Comment | Comment | comments.txt: inefficient double column C5 |
Summary
| Module | Module | M1009 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 3 | |
| BumpBondingDefects | Bump Bonding Defects | 2 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 150/300 | 99.80/99.52 | % |
| Noise | Mean Noise | 337 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.80 | 99.56 | 0.24 | 172.4 | 0 | 57.5 | 0/0 | 0 | 3809 | 337 | 848 |
|
Chip 1
|
A
|
0 | 0 | 99.80 | 99.53 | 0.29 | 197.5 | 0 | 65.2 | 0/0 | 0 | 3742 | 356 | 1136 |
|
Chip 2
|
A
|
0 | 0 | 99.80 | 99.49 | 0.35 | 181.4 | 0 | 59.3 | 0/0 | 0 | 3784 | 339 | 885 |
|
Chip 3
|
A
|
0 | 0 | 99.81 | 99.51 | 0.36 | 141.9 | 0 | 46.7 | 0/0 | 0 | 3827 | 311 | 524 |
|
Chip 4
|
A
|
0 | 0 | 99.79 | 99.46 | 0.25 | 130.8 | 0 | 43.4 | 0/0 | 0 | 3867 | 302 | 408 |
|
Chip 5
|
C
|
0 | 0 | 99.81 | 99.53 | 0.36 | 215.0 | 0 | 70.8 | 0/0 | 2 | 3946 | 387 | 1522 |
|
Chip 6
|
A
|
0 | 0 | 99.81 | 99.50 | 0.39 | 204.0 | 0 | 66.9 | 0/0 | 0 | 3742 | 346 | 975 |
|
Chip 7
|
A
|
0 | 0 | 99.78 | 99.47 | 0.5 | 226.6 | 0 | 74.5 | 0/0 | 0 | 3786 | 334 | 867 |
|
Chip 8
|
A
|
0 | 0 | 99.80 | 99.53 | 0.4 | 258.0 | 0 | 84.3 | 0/0 | 0 | 3764 | 347 | 1044 |
|
Chip 9
|
A
|
0 | 0 | 99.83 | 99.59 | 0.29 | 235.8 | 0 | 76.1 | 0/0 | 0 | 3814 | 329 | 826 |
|
Chip 10
|
A
|
0 | 0 | 99.81 | 99.52 | 0.42 | 224.2 | 0 | 72.1 | 0/0 | 0 | 3515 | 339 | 904 |
|
Chip 11
|
A
|
1 | 0 | 99.81 | 99.51 | 0.27 | 163.7 | 0 | 54.1 | 0/0 | 0 | 3757 | 334 | 795 |
|
Chip 12
|
A
|
1 | 0 | 99.81 | 99.57 | 0.25 | 152.4 | 1 | 50.1 | 0/0 | 0 | 3804 | 311 | 548 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 99.57 | 0.32 | 213.8 | 0 | 68.8 | 0/0 | 0 | 3793 | 333 | 835 |
|
Chip 14
|
A
|
1 | 0 | 99.80 | 99.44 | 0.24 | 172.9 | 1 | 56.8 | 0/0 | 0 | 3796 | 328 | 692 |
|
Chip 15
|
A
|
0 | 0 | 99.80 | 99.51 | 0.26 | 201.9 | 0 | 66.0 | 0/0 | 0 | 3775 | 358 | 1153 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-24 | |
| TestTime | Test Time | 15:14 | |
| TestDuration | Duration | 1:3:41 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-11-g3f3decf on branch master
