Test Date: 2016-10-24 12:21
Analysis date: 2016-10-24 20:16
Analysis date: 2016-10-24 20:16
M1007 XRayHRQualification
Summary
| Module | Module | M1007 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 36 | |
| BumpBondingDefects | Bump Bonding Defects | 36 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.83/99.54 | % |
| Noise | Mean Noise | 353 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.83 | 99.62 | 0.3 | 197.7 | 1 | 64.8 | 0/0 | 0 | 3307 | 353 | 1062 |
|
Chip 1
|
A
|
10 | 0 | 99.82 | 99.67 | 0.26 | 167.8 | 10 | 55.6 | 0/0 | 0 | 3235 | 352 | 1089 |
|
Chip 2
|
A
|
1 | 0 | 99.85 | 99.47 | 0.28 | 165.6 | 1 | 54.9 | 0/0 | 0 | 2166 | 320 | 648 |
|
Chip 3
|
A
|
0 | 0 | 99.83 | 99.54 | 0.26 | 145.4 | 0 | 48.1 | 0/0 | 0 | 2355 | 326 | 703 |
|
Chip 4
|
A
|
0 | 0 | 99.84 | 99.43 | 0.21 | 126.1 | 0 | 41.9 | 0/0 | 0 | 2355 | 316 | 551 |
|
Chip 5
|
A
|
0 | 0 | 99.83 | 99.55 | 0.71 | 194.4 | 0 | 63.5 | 0/0 | 0 | 2253 | 349 | 1063 |
|
Chip 6
|
A
|
0 | 0 | 99.84 | 99.54 | 0.31 | 221.6 | 0 | 72.2 | 0/0 | 0 | 7279 | 365 | 1249 |
|
Chip 7
|
A
|
0 | 0 | 99.82 | 99.53 | 0.34 | 283.2 | 0 | 93.8 | 0/0 | 0 | 2446 | 401 | 1778 |
|
Chip 8
|
A
|
1 | 0 | 99.82 | 99.58 | 0.4 | 251.9 | 1 | 82.5 | 0/0 | 0 | 117982 | 368 | 1311 |
|
Chip 9
|
A
|
0 | 0 | 99.83 | 99.55 | 0.41 | 250.8 | 0 | 81.9 | 0/0 | 0 | 1562 | 382 | 1535 |
|
Chip 10
|
A
|
0 | 0 | 99.84 | 99.58 | 0.24 | 209.2 | 0 | 68.5 | 0/0 | 0 | 2281 | 333 | 815 |
|
Chip 11
|
A
|
0 | 0 | 99.79 | 99.51 | 0.34 | 163.9 | 0 | 54.4 | 0/0 | 0 | 2415 | 368 | 1290 |
|
Chip 12
|
A
|
0 | 0 | 99.80 | 99.38 | 0.22 | 146.5 | 0 | 48.5 | 0/0 | 0 | 2263 | 345 | 943 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 99.68 | 0.34 | 225.7 | 0 | 73.6 | 0/0 | 0 | 3111 | 385 | 1575 |
|
Chip 14
|
A
|
1 | 0 | 99.82 | 99.59 | 0.23 | 186.6 | 1 | 61.2 | 0/0 | 0 | 2502 | 370 | 1306 |
|
Chip 15
|
A
|
22 | 0 | 99.83 | 99.46 | 0.19 | 171.5 | 22 | 57.0 | 0/0 | 0 | 2472 | 316 | 607 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-24 | |
| TestTime | Test Time | 12:21 | |
| TestDuration | Duration | 0:34:12 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 13 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
