Test Date: 2016-10-24 12:21
Analysis date: 2016-10-24 20:13
Analysis date: 2016-10-24 20:13
M1006 XRayHRQualification
Summary
| Module | Module | M1006 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 27 | |
| BumpBondingDefects | Bump Bonding Defects | 27 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.63 | % |
| Noise | Mean Noise | 348 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.81 | 99.57 | 0.26 | 226.1 | 1 | 73.0 | 0/0 | 0 | 2538 | 369 | 1327 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.59 | 0.24 | 190.7 | 0 | 62.3 | 0/0 | 0 | 3415 | 360 | 1213 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.54 | 0.25 | 216.7 | 0 | 71.2 | 0/0 | 0 | 2309 | 352 | 1125 |
|
Chip 3
|
A
|
4 | 0 | 99.84 | 99.52 | 0.22 | 138.4 | 4 | 45.9 | 0/0 | 0 | 2108 | 351 | 1088 |
|
Chip 4
|
A
|
3 | 0 | 99.83 | 99.49 | 0.13 | 120.8 | 3 | 39.6 | 0/0 | 0 | 2508 | 340 | 910 |
|
Chip 5
|
A
|
0 | 0 | 99.82 | 99.35 | 0.24 | 144.0 | 0 | 47.3 | 0/0 | 0 | 2142 | 336 | 861 |
|
Chip 6
|
A
|
2 | 0 | 99.81 | 99.89 | 0.22 | 130.3 | 2 | 42.7 | 0/0 | 0 | 2748 | 335 | 866 |
|
Chip 7
|
A
|
5 | 0 | 99.78 | 99.68 | 0.15 | 136.3 | 5 | 44.7 | 0/0 | 0 | 2181 | 352 | 1060 |
|
Chip 8
|
A
|
3 | 0 | 99.79 | 100.13 | 0.24 | 144.7 | 3 | 47.3 | 0/0 | 0 | 1929 | 380 | 1464 |
|
Chip 9
|
A
|
2 | 0 | 99.82 | 99.26 | 0.13 | 120.1 | 2 | 39.5 | 0/0 | 0 | 2864 | 332 | 783 |
|
Chip 10
|
A
|
1 | 0 | 99.79 | 99.51 | 0.15 | 148.6 | 1 | 49.0 | 0/0 | 0 | 2213 | 365 | 1244 |
|
Chip 11
|
A
|
2 | 0 | 99.81 | 99.56 | 0.13 | 117.7 | 2 | 39.1 | 0/0 | 0 | 1866 | 347 | 1014 |
|
Chip 12
|
A
|
1 | 0 | 99.84 | 99.78 | 0.16 | 98.5 | 1 | 32.8 | 0/0 | 0 | 2387 | 287 | 350 |
|
Chip 13
|
A
|
1 | 0 | 99.82 | 99.93 | 0.19 | 153.2 | 1 | 50.3 | 0/0 | 0 | 2657 | 357 | 1075 |
|
Chip 14
|
A
|
1 | 0 | 99.82 | 99.72 | 0.31 | 184.4 | 1 | 60.5 | 0/0 | 0 | 2709 | 351 | 1015 |
|
Chip 15
|
A
|
1 | 0 | 99.79 | 99.51 | 0.33 | 215.5 | 1 | 70.2 | 0/0 | 0 | 2280 | 360 | 1165 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-24 | |
| TestTime | Test Time | 12:21 | |
| TestDuration | Duration | 0:34:12 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 13 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
