Test Date: 2016-10-31 10:19
Analysis date: 2016-10-31 11:24
Analysis date: 2016-10-31 11:24
M1005 XRayHRQualification
Summary
| Module | Module | M1005 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 14/1/1 | |
| PixelDefects | Total Pixel Defects | 128 | |
| BumpBondingDefects | Bump Bonding Defects | 127 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 150/300 | 99.81/99.54 | % |
| Noise | Mean Noise | 317 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
2 | 0 | 99.82 | 99.61 | 0.25 | 60.0 | 181.8 | 4 | 0/0 | 0 | 3839 | 310 | 492 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 99.56 | 0.19 | 56.6 | 170.4 | 0 | 0/0 | 0 | 3847 | 308 | 471 |
|
Chip 2
|
A
|
1 | 0 | 99.82 | 99.53 | 0.31 | 69.8 | 211.9 | 2 | 0/0 | 0 | 3810 | 310 | 555 |
|
Chip 3
|
C
|
0 | 0 | 99.80 | 99.48 | 0.23 | 53.2 | 158.4 | 0 | 0/0 | 2 | 3875 | 301 | 417 |
|
Chip 4
|
A
|
0 | 0 | 99.82 | 99.57 | 0.31 | 54.8 | 164.9 | 0 | 0/0 | 0 | 3845 | 325 | 699 |
|
Chip 5
|
A
|
0 | 0 | 99.81 | 99.52 | 0.3 | 61.7 | 188.2 | 0 | 0/0 | 0 | 3788 | 320 | 608 |
|
Chip 6
|
A
|
1 | 0 | 99.82 | 99.56 | 0.3 | 72.2 | 217.9 | 1 | 0/0 | 0 | 3778 | 337 | 878 |
|
Chip 7
|
B
|
81 | 0 | 99.68 | 99.48 | 30.44 | 71.2 | 213.7 | 83 | 0/0 | 0 | 3828 | 329 | 791 |
|
Chip 8
|
A
|
0 | 0 | 99.83 | 99.57 | 0.34 | 73.9 | 225.2 | 0 | 0/0 | 0 | 3875 | 297 | 414 |
|
Chip 9
|
A
|
1 | 0 | 99.79 | 99.49 | 0.39 | 76.9 | 233.6 | 1 | 0/0 | 0 | 3818 | 322 | 693 |
|
Chip 10
|
A
|
0 | 0 | 99.81 | 99.53 | 0.39 | 82.1 | 251.5 | 0 | 0/0 | 0 | 3749 | 340 | 966 |
|
Chip 11
|
A
|
16 | 0 | 99.80 | 99.56 | 0.28 | 54.4 | 163.7 | 21 | 0/0 | 0 | 3790 | 322 | 640 |
|
Chip 12
|
A
|
21 | 0 | 99.84 | 99.59 | 0.29 | 50.0 | 152.2 | 28 | 0/0 | 0 | 3872 | 301 | 395 |
|
Chip 13
|
A
|
4 | 0 | 99.81 | 99.48 | 0.35 | 68.8 | 210.3 | 3 | 0/0 | 0 | 3800 | 332 | 801 |
|
Chip 14
|
A
|
1 | 0 | 99.81 | 99.54 | 0.33 | 62.5 | 191.1 | 1 | 0/0 | 0 | 3840 | 320 | 638 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 99.57 | 0.28 | 66.1 | 201.9 | 0 | 0/0 | 0 | 3892 | 296 | 385 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-31 | |
| TestTime | Test Time | 10:19 | |
| TestDuration | Duration | 0:58:35 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-18-g6921b8e on branch L1Xray
