Test Date: 2016-11-08 14:08
Analysis date: 2016-11-08 15:15
Analysis date: 2016-11-08 15:15
M1004 XRayHRQualification
Summary
| Module | Module | M1004 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 3 | |
| BumpBondingDefects | Bump Bonding Defects | 3 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 150/300 | 99.81/99.52 | % |
| Noise | Mean Noise | 351 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.81 | 99.53 | 0.4 | 266.6 | 0 | 85.7 | 0/0 | 0 | 3718 | 376 | 1468 |
|
Chip 1
|
C
|
0 | 0 | 99.79 | 99.42 | 6.39 | 241.0 | 0 | 79.2 | 0/0 | 2 | 3649 | 360 | 1256 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.58 | 0.35 | 273.3 | 0 | 89.2 | 0/0 | 0 | 3718 | 364 | 1337 |
|
Chip 3
|
A
|
0 | 0 | 99.82 | 99.56 | 0.3 | 160.7 | 0 | 53.2 | 0/0 | 0 | 3810 | 312 | 587 |
|
Chip 4
|
A
|
0 | 0 | 99.79 | 99.56 | 0.26 | 154.6 | 0 | 51.4 | 0/0 | 0 | 3753 | 358 | 1216 |
|
Chip 5
|
A
|
1 | 0 | 99.81 | 99.54 | 0.32 | 182.6 | 1 | 60.3 | 0/0 | 0 | 3768 | 359 | 1229 |
|
Chip 6
|
A
|
0 | 0 | 99.82 | 99.49 | 0.31 | 168.2 | 0 | 55.3 | 0/0 | 0 | 3728 | 347 | 1012 |
|
Chip 7
|
A
|
1 | 0 | 99.81 | 99.50 | 0.27 | 177.9 | 1 | 59.2 | 0/0 | 0 | 3726 | 376 | 1448 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.47 | 0.33 | 155.8 | 0 | 51.6 | 0/0 | 0 | 3843 | 346 | 999 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.57 | 0.18 | 149.1 | 0 | 49.3 | 0/0 | 0 | 3808 | 334 | 818 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.47 | 0.27 | 179.6 | 0 | 59.0 | 0/0 | 0 | 3294 | 340 | 905 |
|
Chip 11
|
A
|
0 | 0 | 99.83 | 99.49 | 0.21 | 139.8 | 0 | 46.8 | 0/0 | 0 | 3787 | 329 | 800 |
|
Chip 12
|
A
|
0 | 0 | 99.81 | 99.54 | 0.22 | 155.7 | 0 | 51.8 | 0/0 | 0 | 3808 | 337 | 909 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 99.58 | 0.28 | 222.0 | 0 | 73.0 | 0/0 | 0 | 3747 | 348 | 1070 |
|
Chip 14
|
A
|
1 | 0 | 99.82 | 99.54 | 0.26 | 220.0 | 1 | 72.4 | 0/0 | 0 | 3789 | 339 | 969 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 99.56 | 0.37 | 278.6 | 0 | 89.3 | 0/0 | 0 | 3727 | 386 | 1597 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-08 | |
| TestTime | Test Time | 14:08 | |
| TestDuration | Duration | 0:59:31 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
v1.1.1-1-g54fa876 on branch master
