Test Date: 2016-11-09 09:48
Analysis date: 2016-11-09 10:58
Analysis date: 2016-11-09 10:58
M1002 XRayHRQualification
Summary
| Module | Module | M1002 | |
| Grade | Grade | B | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 14/2/0 | |
| PixelDefects | Total Pixel Defects | 109 | |
| BumpBondingDefects | Bump Bonding Defects | 103 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.54 | % |
| Noise | Mean Noise | 316 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
5 | 0 | 99.82 | 99.60 | 0.25 | 69.0 | 215.8 | 3 | 0/0 | 0 | 3866 | 301 | 425 |
|
Chip 1
|
A
|
0 | 0 | 99.81 | 99.57 | 0.34 | 75.2 | 233.0 | 0 | 0/0 | 0 | 3810 | 313 | 579 |
|
Chip 2
|
A
|
1 | 0 | 99.82 | 99.56 | 0.25 | 70.4 | 217.9 | 1 | 0/0 | 0 | 3779 | 334 | 903 |
|
Chip 3
|
A
|
6 | 0 | 99.78 | 99.56 | 0.28 | 45.5 | 138.4 | 3 | 0/0 | 0 | 3860 | 294 | 384 |
|
Chip 4
|
A
|
1 | 0 | 99.84 | 99.51 | 0.3 | 46.5 | 141.0 | 1 | 0/0 | 0 | 3360 | 309 | 526 |
|
Chip 5
|
A
|
3 | 0 | 99.81 | 99.50 | 0.32 | 58.0 | 176.3 | 3 | 0/0 | 0 | 3785 | 324 | 721 |
|
Chip 6
|
A
|
1 | 0 | 99.79 | 99.44 | 0.24 | 47.5 | 146.2 | 1 | 0/0 | 0 | 3889 | 299 | 346 |
|
Chip 7
|
A
|
0 | 0 | 99.79 | 99.21 | 0.55 | 46.5 | 144.2 | 0 | 0/0 | 0 | 3857 | 318 | 611 |
|
Chip 8
|
A
|
1 | 0 | 99.81 | 99.58 | 0.28 | 47.0 | 143.6 | 1 | 0/0 | 0 | 3817 | 311 | 498 |
|
Chip 9
|
A
|
1 | 0 | 99.80 | 99.65 | 0.25 | 50.7 | 154.8 | 1 | 0/0 | 0 | 3810 | 347 | 1037 |
|
Chip 10
|
A
|
0 | 0 | 99.84 | 99.58 | 0.2 | 49.0 | 151.5 | 0 | 0/0 | 0 | 3870 | 313 | 534 |
|
Chip 11
|
A
|
8 | 0 | 99.83 | 99.51 | 0.15 | 35.4 | 107.9 | 8 | 0/0 | 0 | 3643 | 273 | 209 |
|
Chip 12
|
B
|
13 | 0 | 99.82 | 99.55 | 0.28 | 47.8 | 145.0 | 13 | 0/0 | 0 | 3807 | 323 | 705 |
|
Chip 13
|
B
|
38 | 0 | 99.82 | 99.63 | 0.36 | 64.9 | 199.2 | 38 | 0/0 | 0 | 3491 | 344 | 977 |
|
Chip 14
|
A
|
28 | 0 | 99.82 | 99.55 | 0.31 | 68.2 | 209.7 | 29 | 0/0 | 0 | 3845 | 311 | 572 |
|
Chip 15
|
A
|
3 | 0 | 99.82 | 99.57 | 0.39 | 75.8 | 238.6 | 2 | 0/0 | 0 | 3787 | 338 | 941 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-09 | |
| TestTime | Test Time | 09:48 | |
| TestDuration | Duration | 0:59:39 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
v1.1.1-1-g54fa876 on branch master
