Test Date: 2016-11-09 09:48
Analysis date: 2016-11-09 11:00
Analysis date: 2016-11-09 11:00
M1000 XRayHRQualification
Summary
| Module | Module | M1000 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 47 | |
| BumpBondingDefects | Bump Bonding Defects | 47 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.60 | % |
| Noise | Mean Noise | 330 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
4 | 0 | 99.83 | 99.57 | 0.29 | 75.5 | 225.9 | 4 | 0/0 | 0 | 3772 | 338 | 968 |
|
Chip 1
|
A
|
0 | 0 | 99.81 | 99.64 | 0.29 | 72.0 | 216.7 | 0 | 0/0 | 0 | 3609 | 336 | 855 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.58 | 0.25 | 63.5 | 188.2 | 0 | 0/0 | 0 | 3831 | 300 | 397 |
|
Chip 3
|
A
|
4 | 0 | 99.81 | 99.63 | 0.25 | 55.9 | 166.8 | 4 | 0/0 | 0 | 3579 | 320 | 648 |
|
Chip 4
|
A
|
0 | 0 | 99.82 | 99.62 | 0.21 | 63.7 | 195.2 | 0 | 0/0 | 0 | 3724 | 337 | 863 |
|
Chip 5
|
A
|
1 | 0 | 99.80 | 99.59 | 0.35 | 80.2 | 244.4 | 1 | 0/0 | 0 | 3772 | 317 | 649 |
|
Chip 6
|
A
|
2 | 0 | 99.81 | 99.66 | 0.26 | 65.5 | 197.3 | 2 | 0/0 | 0 | 3840 | 296 | 358 |
|
Chip 7
|
A
|
0 | 0 | 99.82 | 99.54 | 0.46 | 99.5 | 299.0 | 0 | 0/0 | 0 | 3718 | 369 | 1346 |
|
Chip 8
|
A
|
0 | 0 | 99.83 | 99.59 | 0.41 | 100.5 | 313.8 | 0 | 0/0 | 0 | 3816 | 365 | 1340 |
|
Chip 9
|
A
|
3 | 0 | 99.83 | 99.58 | 0.33 | 81.5 | 246.4 | 3 | 0/0 | 0 | 3812 | 347 | 1037 |
|
Chip 10
|
A
|
2 | 0 | 99.83 | 99.54 | 0.47 | 87.9 | 271.4 | 2 | 0/0 | 0 | 3733 | 349 | 1130 |
|
Chip 11
|
A
|
1 | 0 | 99.83 | 99.62 | 0.19 | 58.6 | 178.9 | 1 | 0/0 | 0 | 3831 | 322 | 695 |
|
Chip 12
|
A
|
24 | 0 | 99.82 | 99.56 | 0.21 | 55.4 | 168.2 | 24 | 0/0 | 0 | 3537 | 328 | 769 |
|
Chip 13
|
A
|
5 | 0 | 99.82 | 99.60 | 0.27 | 72.1 | 219.3 | 5 | 0/0 | 0 | 3750 | 317 | 628 |
|
Chip 14
|
A
|
1 | 0 | 99.82 | 99.60 | 0.32 | 73.3 | 225.9 | 1 | 0/0 | 0 | 3800 | 326 | 783 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 99.63 | 0.25 | 64.8 | 194.2 | 0 | 0/0 | 0 | 3837 | 305 | 486 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-09 | |
| TestTime | Test Time | 09:48 | |
| TestDuration | Duration | 0:59:39 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 13 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
v1.1.1-1-g54fa876 on branch master
