Test Date: 2016-04-25 14:49
Analysis date: 2016-04-25 16:39
Analysis date: 2016-04-25 16:39
M3633 XRayHRQualification
Summary
| Module | Module | M3633 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 11 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 10 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.03 | % |
| Noise | Mean Noise | 176 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
3 | 0 | 99.85 | 98.98 | 0.61 | 29.6 | 78.0 | 0 | 0/0 | 0 | 1950 | 181 | 2 |
|
Chip 1
|
A
|
3 | 0 | 99.85 | 99.15 | 0.45 | 31.0 | 81.8 | 0 | 0/0 | 0 | 1842 | 182 | 3 |
|
Chip 2
|
A
|
0 | 0 | 99.85 | 99.25 | 0.39 | 27.7 | 72.6 | 0 | 0/0 | 0 | 1915 | 172 | 0 |
|
Chip 3
|
A
|
1 | 0 | 99.83 | 99.01 | 0.84 | 52.0 | 135.1 | 0 | 0/0 | 0 | 2082 | 172 | 1 |
|
Chip 4
|
A
|
1 | 0 | 99.85 | 99.26 | 0.74 | 54.6 | 142.3 | 0 | 0/0 | 0 | 2078 | 179 | 1 |
|
Chip 5
|
A
|
0 | 0 | 99.85 | 99.26 | 0.93 | 58.9 | 150.1 | 0 | 0/0 | 0 | 2112 | 162 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.85 | 99.05 | 0.7 | 59.4 | 154.2 | 0 | 0/0 | 0 | 2126 | 178 | 0 |
|
Chip 7
|
A
|
1 | 0 | 99.84 | 99.08 | 0.69 | 57.9 | 150.4 | 0 | 0/0 | 0 | 2102 | 172 | 1 |
|
Chip 8
|
A
|
0 | 0 | 99.83 | 99.13 | 0.67 | 65.1 | 169.5 | 0 | 0/0 | 0 | 2122 | 192 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.86 | 99.18 | 0.78 | 63.9 | 164.5 | 0 | 0/0 | 0 | 2100 | 184 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.86 | 99.28 | 0.64 | 71.7 | 185.9 | 0 | 0/0 | 0 | 2170 | 171 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.88 | 99.28 | 0.82 | 57.3 | 148.6 | 0 | 0/0 | 0 | 2129 | 169 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.93 | 98.61 | 64.34 | 48.4 | 125.4 | 0 | 0/0 | 0 | 2044 | 165 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.64 | 98.49 | 21.55 | 31.8 | 83.4 | 0 | 0/0 | 0 | 1966 | 177 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.92 | 98.74 | 4.05 | 35.7 | 94.4 | 0 | 0/0 | 0 | 1991 | 181 | 0 |
|
Chip 15
|
A
|
2 | 0 | 99.96 | 98.66 | 4.79 | 34.1 | 89.9 | 0 | 0/0 | 0 | 1907 | 183 | 2 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-04-25 | |
| TestTime | Test Time | 14:49 | |
| TestDuration | Duration | 1:9:59 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 13903 | |
| nWarnings | # Warnings | 24 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 8896 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 10 | |
| message_tokenchain_count | Token Chain Length | 8872 | |
| message_readback_count | Readback start marker | 14 |
MoReWeb-v0.7.3-14-g740d8b3 on branch psi46master
