Test Date: 2016-04-25 14:49
Analysis date: 2016-04-25 16:42
X-ray Calibration - Spectrum
| Slope |
avrg Slope |
49.1709375 |
|
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
49.1709375 |
|
| medianSlope |
median Slope |
49.1955 |
|
| minSlope |
min Slope |
45.962 |
|
| maxSlope |
max Slope |
51.411 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
-59.8300625 |
|
| medianOffset |
median Offset |
-39.2005 |
|
| minOffset |
min Offset |
-202.64 |
|
| maxOffset |
max Offset |
56.005 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
2.1508125 |
|
| medianchi2 |
median chi2 |
1.715 |
|
| minchi2 |
min chi2 |
0.003 |
|
| maxchi2 |
max chi2 |
7.514 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
49.9 e- / Vcal
|
0.1 e- / Vcal
|
-33.0 e-
|
8.2 e-
|
|
1
|
50.6 e- / Vcal
|
0.2 e- / Vcal
|
-53.8 e-
|
19.7 e-
|
|
2
|
49.1 e- / Vcal
|
0.2 e- / Vcal
|
-24.9 e-
|
21.5 e-
|
|
3
|
50.3 e- / Vcal
|
0.2 e- / Vcal
|
-109.9 e-
|
17.8 e-
|
|
4
|
49.1 e- / Vcal
|
0.1 e- / Vcal
|
-33.8 e-
|
9.7 e-
|
|
5
|
46.0 e- / Vcal
|
0.1 e- / Vcal
|
-39.6 e-
|
6.2 e-
|
|
6
|
47.3 e- / Vcal
|
0.1 e- / Vcal
|
32.1 e-
|
9.2 e-
|
|
7
|
49.2 e- / Vcal
|
0.1 e- / Vcal
|
-159.8 e-
|
17.5 e-
|
|
8
|
48.4 e- / Vcal
|
0.2 e- / Vcal
|
-202.6 e-
|
18.1 e-
|
|
9
|
49.7 e- / Vcal
|
0.1 e- / Vcal
|
-133.2 e-
|
7.6 e-
|
|
10
|
49.8 e- / Vcal
|
0.2 e- / Vcal
|
16.6 e-
|
17.9 e-
|
|
11
|
51.4 e- / Vcal
|
0.1 e- / Vcal
|
-161.0 e-
|
7.6 e-
|
|
12
|
48.5 e- / Vcal
|
0.1 e- / Vcal
|
-52.2 e-
|
7.9 e-
|
|
13
|
48.2 e- / Vcal
|
0.2 e- / Vcal
|
-38.8 e-
|
22.1 e-
|
|
14
|
50.2 e- / Vcal
|
0.2 e- / Vcal
|
-19.2 e-
|
19.5 e-
|
|
15
|
49.2 e- / Vcal
|
0.1 e- / Vcal
|
56.0 e-
|
8.7 e-
|
|
Average
|
49.2 e- / Vcal
|
|
-59.8 e-
|
|
|
Median
|
97.6 e- / Vcal
|
|
-362.4 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
