Test Date: 2016-04-29 11:31
Analysis date: 2016-04-29 15:02
X-ray Calibration - Spectrum
| Slope |
avrg Slope |
47.71475 |
|
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
47.71475 |
|
| medianSlope |
median Slope |
46.9325 |
|
| minSlope |
min Slope |
45.715 |
|
| maxSlope |
max Slope |
51.346 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
-47.51275 |
|
| medianOffset |
median Offset |
-36.021 |
|
| minOffset |
min Offset |
-248.529 |
|
| maxOffset |
max Offset |
170.286 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
3.77413333333 |
|
| medianchi2 |
median chi2 |
0.549 |
|
| minchi2 |
min chi2 |
0.001 |
|
| maxchi2 |
max chi2 |
29.758 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
47.2 e- / Vcal
|
0.2 e- / Vcal
|
-116.4 e-
|
18.9 e-
|
|
1
|
46.6 e- / Vcal
|
0.2 e- / Vcal
|
-147.0 e-
|
21.4 e-
|
|
2
|
49.0 e- / Vcal
|
0.2 e- / Vcal
|
-50.0 e-
|
21.7 e-
|
|
3
|
46.3 e- / Vcal
|
0.1 e- / Vcal
|
-248.5 e-
|
17.9 e-
|
|
4
|
46.4 e- / Vcal
|
0.1 e- / Vcal
|
-89.3 e-
|
16.8 e-
|
|
5
|
48.5 e- / Vcal
|
0.1 e- / Vcal
|
170.3 e-
|
6.0 e-
|
|
6
|
51.3 e- / Vcal
|
0.1 e- / Vcal
|
-195.5 e-
|
9.1 e-
|
|
7
|
50.3 e- / Vcal
|
0.1 e- / Vcal
|
-18.4 e-
|
6.0 e-
|
|
8
|
46.1 e- / Vcal
|
0.1 e- / Vcal
|
-25.0 e-
|
16.1 e-
|
|
9
|
46.7 e- / Vcal
|
0.1 e- / Vcal
|
119.8 e-
|
15.9 e-
|
|
10
|
45.7 e- / Vcal
|
0.1 e- / Vcal
|
-16.5 e-
|
17.2 e-
|
|
11
|
50.3 e- / Vcal
|
0.1 e- / Vcal
|
39.0 e-
|
7.3 e-
|
|
12
|
46.1 e- / Vcal
|
0.1 e- / Vcal
|
-31.3 e-
|
5.5 e-
|
|
13
|
47.5 e- / Vcal
|
0.1 e- / Vcal
|
-40.7 e-
|
8.5 e-
|
|
14
|
48.8 e- / Vcal
|
0.1 e- / Vcal
|
-11.7 e-
|
8.0 e-
|
|
15
|
46.7 e- / Vcal
|
0.2 e- / Vcal
|
-99.0 e-
|
20.3 e-
|
|
Average
|
47.7 e- / Vcal
|
|
-47.5 e-
|
|
|
Median
|
96.4 e- / Vcal
|
|
-43.3 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
MoReWeb-v0.7.3-14-g740d8b3 on branch psi46master
