Test Date: 2016-04-29 11:31
Analysis date: 2016-04-29 15:02
Analysis date: 2016-04-29 15:02
M3631 XRayHRQualification
Summary
| Module | Module | M3631 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 20 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 17 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.19 | % |
| Noise | Mean Noise | 163 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
3 | 0 | 99.85 | 98.99 | 0.77 | 40.0 | 107.0 | 0 | 0/0 | 0 | 1909 | 177 | 3 |
|
Chip 1
|
A
|
2 | 0 | 99.86 | 99.21 | 0.84 | 41.4 | 110.3 | 0 | 0/0 | 0 | 1912 | 178 | 2 |
|
Chip 2
|
A
|
1 | 0 | 99.84 | 99.25 | 0.56 | 35.9 | 94.8 | 0 | 0/0 | 0 | 1946 | 164 | 1 |
|
Chip 3
|
A
|
0 | 0 | 99.85 | 99.26 | 0.71 | 68.3 | 178.3 | 0 | 0/0 | 0 | 2167 | 164 | 0 |
|
Chip 4
|
A
|
1 | 0 | 99.84 | 99.07 | 1.07 | 70.3 | 181.4 | 0 | 0/0 | 0 | 2128 | 166 | 1 |
|
Chip 5
|
A
|
6 | 0 | 99.83 | 99.26 | 0.86 | 80.3 | 205.7 | 0 | 0/0 | 0 | 2086 | 155 | 4 |
|
Chip 6
|
A
|
1 | 0 | 99.87 | 99.21 | 1.01 | 71.7 | 183.9 | 0 | 0/0 | 0 | 2146 | 150 | 1 |
|
Chip 7
|
A
|
1 | 0 | 99.85 | 99.22 | 1.25 | 75.9 | 195.9 | 0 | 0/0 | 0 | 2171 | 144 | 1 |
|
Chip 8
|
A
|
0 | 0 | 99.83 | 99.25 | 0.88 | 87.3 | 221.6 | 0 | 0/0 | 0 | 2266 | 156 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.86 | 99.26 | 0.77 | 76.3 | 194.6 | 0 | 0/0 | 0 | 2185 | 161 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.85 | 99.26 | 0.48 | 81.3 | 207.8 | 0 | 0/0 | 0 | 2234 | 163 | 0 |
|
Chip 11
|
A
|
1 | 0 | 99.86 | 99.24 | 0.63 | 59.6 | 154.7 | 0 | 0/0 | 0 | 2105 | 155 | 1 |
|
Chip 12
|
A
|
0 | 0 | 99.87 | 99.26 | 0.7 | 65.9 | 171.5 | 0 | 0/0 | 0 | 2174 | 168 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.85 | 99.16 | 0.59 | 38.4 | 100.8 | 0 | 0/0 | 0 | 2035 | 169 | 0 |
|
Chip 14
|
A
|
2 | 0 | 99.82 | 98.86 | 0.78 | 39.2 | 103.2 | 0 | 0/0 | 0 | 1947 | 162 | 2 |
|
Chip 15
|
A
|
2 | 0 | 99.86 | 99.24 | 0.75 | 38.4 | 102.0 | 0 | 0/0 | 0 | 1940 | 180 | 1 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-04-29 | |
| TestTime | Test Time | 11:31 | |
| TestDuration | Duration | 1:6:34 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v0.7.3-14-g740d8b3 on branch psi46master
