Test Date: 2015-11-04 10:51
Analysis date: 2015-11-23 15:59
Analysis date: 2015-11-23 15:59
M3521 XRayHRQualification
Summary
| Module | Module | M3521 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 3 | |
| BumpBondingDefects | Bump Bonding Defects | 3 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.22 | % |
| Noise | Mean Noise | 137 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.80 | 99.00 | 0.77 | 30.8 | 91.3 | 0 | 0/0 | 0 | 5210 | 143 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.85 | 99.27 | 0.75 | 31.5 | 94.4 | 0 | 0/0 | 0 | 5019 | 136 | 0 |
|
Chip 2
|
A
|
3 | 0 | 99.71 | 98.69 | 23.22 | 27.9 | 84.7 | 3 | 0/0 | 0 | 5610 | 125 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.34 | 0.46 | 54.6 | 155.1 | 0 | 0/0 | 0 | 4939 | 146 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.34 | 1.01 | 54.7 | 157.3 | 0 | 0/0 | 0 | 5472 | 133 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.85 | 99.27 | 6.84 | 62.6 | 175.3 | 0 | 0/0 | 0 | 5259 | 136 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.82 | 99.27 | 3.90 | 64.6 | 183.1 | 0 | 0/0 | 0 | 5391 | 132 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.88 | 99.29 | 0.82 | 73.4 | 205.4 | 0 | 0/0 | 0 | 5115 | 150 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.86 | 99.39 | 0.81 | 70.0 | 196.4 | 0 | 0/0 | 0 | 5399 | 143 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.86 | 99.34 | 0.49 | 68.9 | 195.4 | 0 | 0/0 | 0 | 5810 | 141 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.86 | 99.32 | 0.84 | 68.9 | 191.8 | 0 | 0/0 | 0 | 4759 | 136 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.87 | 99.30 | 0.66 | 54.2 | 155.1 | 0 | 0/0 | 0 | 5292 | 135 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.86 | 99.16 | 0.59 | 53.0 | 154.3 | 0 | 0/0 | 0 | 5914 | 129 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.84 | 99.17 | 1.05 | 28.4 | 85.8 | 0 | 0/0 | 0 | 4993 | 142 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.88 | 99.30 | 0.94 | 26.6 | 80.5 | 0 | 0/0 | 0 | 5003 | 132 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.84 | 99.01 | 1.13 | 28.4 | 85.1 | 0 | 0/0 | 0 | 5545 | 126 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 8 | |
| nWarnings | # Warnings | 1 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 1 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 1 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
