Test Date: 2015-11-03 12:52
Analysis date: 2015-11-23 15:58
Analysis date: 2015-11-23 15:58
M3518 XRayHRQualification
Summary
| Module | Module | M3518 | |
| Grade | Grade | B | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 14/2/0 | |
| PixelDefects | Total Pixel Defects | 224 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 223 | |
| HotPixelDefects | Hot Pixels | 2 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.23 | % |
| Noise | Mean Noise | 167 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.84 | 99.25 | 1.00 | 34.0 | 98.9 | 0 | 0/0 | 0 | 1999 | 169 | 1 |
|
Chip 1
|
B
|
77 | 0 | 99.75 | 98.89 | 6.76 | 35.3 | 104.2 | 0 | 0/0 | 0 | -565 | 189 | 77 |
|
Chip 2
|
B
|
42 | 0 | 99.79 | 99.09 | 5.61 | 29.5 | 88.4 | 0 | 0/0 | 0 | 401 | 176 | 42 |
|
Chip 3
|
A
|
3 | 0 | 99.89 | 99.32 | 0.56 | 51.9 | 149.1 | 0 | 0/0 | 0 | 2022 | 163 | 3 |
|
Chip 4
|
A
|
1 | 0 | 99.89 | 99.34 | 0.51 | 52.6 | 151.8 | 0 | 0/0 | 0 | 2091 | 160 | 1 |
|
Chip 5
|
A
|
6 | 0 | 99.87 | 99.34 | 0.62 | 68.8 | 194.3 | 0 | 0/0 | 0 | 2087 | 161 | 6 |
|
Chip 6
|
A
|
27 | 0 | 99.84 | 99.35 | 1.96 | 61.8 | 176.1 | 0 | 0/0 | 0 | 1328 | 164 | 27 |
|
Chip 7
|
A
|
3 | 0 | 99.88 | 99.30 | 0.63 | 71.3 | 206.2 | 0 | 0/0 | 0 | 2138 | 174 | 3 |
|
Chip 8
|
A
|
6 | 0 | 99.83 | 99.02 | 1.21 | 70.9 | 203.8 | 1 | 0/0 | 0 | 2268 | 162 | 5 |
|
Chip 9
|
A
|
27 | 0 | 99.85 | 99.31 | 1.82 | 59.0 | 168.0 | 0 | 0/0 | 0 | 1235 | 157 | 27 |
|
Chip 10
|
A
|
23 | 0 | 99.80 | 99.29 | 3.35 | 65.7 | 186.4 | 0 | 0/0 | 0 | 1420 | 160 | 23 |
|
Chip 11
|
A
|
0 | 0 | 99.87 | 99.24 | 0.55 | 56.5 | 161.5 | 0 | 0/0 | 0 | 2160 | 162 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.88 | 99.24 | 0.63 | 53.0 | 151.8 | 0 | 0/0 | 0 | 2142 | 160 | 0 |
|
Chip 13
|
A
|
7 | 0 | 99.81 | 99.14 | 4.42 | 29.9 | 89.5 | 0 | 0/0 | 0 | 1754 | 165 | 7 |
|
Chip 14
|
A
|
1 | 0 | 99.86 | 99.28 | 0.87 | 32.0 | 95.3 | 0 | 0/0 | 0 | 1975 | 163 | 1 |
|
Chip 15
|
A
|
0 | 0 | 99.88 | 99.30 | 0.50 | 38.2 | 111.0 | 0 | 0/0 | 0 | 2074 | 188 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 43 | |
| nWarnings | # Warnings | 9 | |
| channel_0_count | Channel 0 | 4 | |
| channel_1_count | Channel 1 | 1 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 1 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 2 | |
| message_notokenpass_count | has NoTokenPass | 2 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
