Test Date: 2015-10-31 11:13
Analysis date: 2015-11-23 15:55
Analysis date: 2015-11-23 15:55
M3513 XRayHRQualification
Summary
| Module | Module | M3513 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 5 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 4 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.88/98.96 | % |
| Noise | Mean Noise | 182 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.87 | 99.06 | 1.01 | 52.6 | 157.7 | 0 | 0/0 | 0 | 2045 | 171 | 0 |
|
Chip 1
|
A
|
1 | 0 | 99.88 | 99.05 | 2.33 | 52.6 | 157.4 | 0 | 0/0 | 0 | 2049 | 178 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.08 | 0.88 | 46.5 | 139.0 | 0 | 0/0 | 0 | 1989 | 193 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.96 | 98.88 | 10.22 | 55.1 | 165.1 | 0 | 0/0 | 0 | 2057 | 178 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.89 | 98.77 | 1.71 | 54.3 | 162.4 | 0 | 0/0 | 0 | 2060 | 176 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.12 | 1.63 | 54.2 | 163.4 | 0 | 0/0 | 0 | 2067 | 171 | 0 |
|
Chip 6
|
A
|
1 | 0 | 99.85 | 99.04 | 2.99 | 51.2 | 153.3 | 0 | 0/0 | 0 | 1992 | 180 | 1 |
|
Chip 7
|
A
|
0 | 0 | 99.87 | 98.88 | 29.20 | 50.8 | 151.8 | 0 | 0/0 | 0 | 2047 | 181 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.85 | 98.83 | 1.79 | 51.5 | 154.5 | 0 | 0/0 | 0 | 1997 | 194 | 0 |
|
Chip 9
|
A
|
2 | 0 | 99.87 | 99.07 | 3.12 | 51.6 | 157.7 | 0 | 0/0 | 0 | 2016 | 191 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.90 | 99.06 | 1.98 | 55.1 | 164.9 | 0 | 0/0 | 0 | 2044 | 189 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.86 | 99.02 | 1.25 | 54.2 | 162.4 | 0 | 0/0 | 0 | 2058 | 182 | 0 |
|
Chip 12
|
A
|
1 | 0 | 100.03 | 98.76 | 14.17 | 55.3 | 165.4 | 0 | 0/0 | 0 | 2067 | 180 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.81 | 98.86 | 1.81 | 45.6 | 136.7 | 0 | 0/0 | 0 | 1975 | 184 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.91 | 98.89 | 13.53 | 52.8 | 157.6 | 0 | 0/0 | 0 | 2068 | 184 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 98.95 | 1.79 | 54.4 | 163.3 | 0 | 0/0 | 0 | 2034 | 185 | 0 |
Errors
| nCriticals | # Criticals | 2 | |
| nErrors | # Errors | 141 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 14 | |
| channel_1_count | Channel 1 | 7 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 12 | |
| message_eventid_count | Event ID mismatch | 4 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 5 | |
| message_datasize_count | Data size criticals | 1 | |
| message_missingevents_count | Missing Event criticals | 1 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
