Test Date: 2015-10-31 11:13
Analysis date: 2015-11-23 15:52
Analysis date: 2015-11-23 15:52
M3512 XRayHRQualification
Summary
| Module | Module | M3512 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 3 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 3 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.84/98.93 | % |
| Noise | Mean Noise | 152 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.85 | 98.85 | 2.15 | 50.8 | 152.0 | 0 | 0/0 | 0 | 5950 | 140 | 0 |
|
Chip 1
|
A
|
1 | 0 | 99.87 | 98.95 | 3.43 | 51.9 | 156.2 | 0 | 0/0 | 0 | 6174 | 156 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.72 | 98.94 | 4.60 | 43.2 | 129.2 | 0 | 0/0 | 0 | 6268 | 166 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 98.85 | 1.24 | 54.2 | 162.0 | 0 | 0/0 | 0 | 6059 | 169 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.95 | 98.77 | 9.92 | 53.3 | 159.2 | 0 | 0/0 | 0 | 5911 | 152 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.89 | 98.98 | 1.48 | 53.6 | 160.3 | 0 | 0/0 | 0 | 6367 | 150 | 0 |
|
Chip 6
|
A
|
1 | 0 | 99.82 | 98.92 | 1.59 | 50.4 | 150.9 | 0 | 0/0 | 0 | 5899 | 148 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.80 | 98.94 | 2.77 | 49.6 | 148.4 | 0 | 0/0 | 0 | 6119 | 152 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.11 | 2.69 | 48.7 | 145.8 | 0 | 0/0 | 0 | 6096 | 146 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.03 | 3.20 | 50.0 | 149.4 | 0 | 0/0 | 0 | 6028 | 156 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.86 | 98.85 | 1.25 | 53.4 | 159.8 | 0 | 0/0 | 0 | 6222 | 160 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.84 | 98.95 | 1.53 | 52.0 | 155.7 | 0 | 0/0 | 0 | 6031 | 145 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.86 | 98.90 | 1.47 | 53.9 | 161.0 | 0 | 0/0 | 0 | 6361 | 137 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 98.83 | 1.45 | 41.7 | 124.9 | 0 | 0/0 | 0 | 6341 | 149 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 99.11 | 1.74 | 51.0 | 153.0 | 0 | 0/0 | 0 | 5949 | 149 | 0 |
|
Chip 15
|
A
|
1 | 0 | 99.86 | 98.90 | 1.45 | 52.7 | 157.4 | 0 | 0/0 | 0 | 6523 | 155 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 9 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 1 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 1 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
