Test Date: 2015-11-04 10:51
Analysis date: 2015-11-23 15:50
X-ray Calibration - Spectrum
| Slope |
avrg Slope |
44.14525 |
|
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
44.14525 |
|
| medianSlope |
median Slope |
44.3525 |
|
| minSlope |
min Slope |
41.42 |
|
| maxSlope |
max Slope |
47.306 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
-52.9036875 |
|
| medianOffset |
median Offset |
-71.881 |
|
| minOffset |
min Offset |
-240.636 |
|
| maxOffset |
max Offset |
223.933 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
2.84625 |
|
| medianchi2 |
median chi2 |
0.7425 |
|
| minchi2 |
min chi2 |
0.069 |
|
| maxchi2 |
max chi2 |
11.412 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
43.6 e- / Vcal
|
0.1 e- / Vcal
|
-89.3 e-
|
8.1 e-
|
|
1
|
44.6 e- / Vcal
|
0.1 e- / Vcal
|
-240.6 e-
|
9.3 e-
|
|
2
|
43.5 e- / Vcal
|
0.2 e- / Vcal
|
223.9 e-
|
24.1 e-
|
|
3
|
43.1 e- / Vcal
|
0.1 e- / Vcal
|
12.5 e-
|
9.2 e-
|
|
4
|
47.3 e- / Vcal
|
0.2 e- / Vcal
|
-71.2 e-
|
21.0 e-
|
|
5
|
44.4 e- / Vcal
|
0.1 e- / Vcal
|
31.8 e-
|
7.9 e-
|
|
6
|
45.2 e- / Vcal
|
0.1 e- / Vcal
|
-170.9 e-
|
9.1 e-
|
|
7
|
41.4 e- / Vcal
|
0.2 e- / Vcal
|
0.1 e-
|
20.6 e-
|
|
8
|
45.1 e- / Vcal
|
0.2 e- / Vcal
|
15.2 e-
|
21.5 e-
|
|
9
|
44.9 e- / Vcal
|
0.2 e- / Vcal
|
8.9 e-
|
20.0 e-
|
|
10
|
42.5 e- / Vcal
|
0.2 e- / Vcal
|
-72.5 e-
|
20.9 e-
|
|
11
|
45.6 e- / Vcal
|
0.1 e- / Vcal
|
-92.8 e-
|
9.0 e-
|
|
12
|
43.6 e- / Vcal
|
0.2 e- / Vcal
|
-150.7 e-
|
20.1 e-
|
|
13
|
41.8 e- / Vcal
|
0.2 e- / Vcal
|
2.6 e-
|
22.5 e-
|
|
14
|
44.3 e- / Vcal
|
0.2 e- / Vcal
|
-127.6 e-
|
22.8 e-
|
|
15
|
45.3 e- / Vcal
|
0.2 e- / Vcal
|
-125.7 e-
|
23.4 e-
|
|
Average
|
44.1 e- / Vcal
|
|
-52.9 e-
|
|
|
Median
|
44.4 e- / Vcal
|
|
-71.2 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
