Test Date: 2015-11-04 10:51
Analysis date: 2015-11-23 15:50
Analysis date: 2015-11-23 15:50
M3508 XRayHRQualification
Summary
| Module | Module | M3508 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 0 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.23 | % |
| Noise | Mean Noise | 150 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.85 | 99.10 | 0.44 | 22.2 | 67.5 | 0 | 0/0 | 0 | 5905 | 155 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.88 | 99.25 | 0.64 | 22.9 | 70.0 | 0 | 0/0 | 0 | 6241 | 148 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.00 | 1.81 | 19.2 | 59.4 | 0 | 0/0 | 0 | 6270 | 155 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.26 | 0.85 | 38.1 | 112.3 | 0 | 0/0 | 0 | 6032 | 150 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.28 | 0.77 | 37.8 | 111.4 | 0 | 0/0 | 0 | 5998 | 142 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.86 | 99.32 | 0.62 | 49.9 | 144.2 | 0 | 0/0 | 0 | 5963 | 145 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.24 | 1.43 | 45.5 | 132.5 | 0 | 0/0 | 0 | 5591 | 150 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.88 | 99.32 | 0.56 | 47.8 | 140.8 | 0 | 0/0 | 0 | 6292 | 157 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.88 | 99.29 | 0.80 | 46.0 | 133.8 | 0 | 0/0 | 0 | 5543 | 143 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.88 | 99.29 | 1.31 | 48.4 | 140.8 | 0 | 0/0 | 0 | 5754 | 142 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.28 | 0.29 | 55.7 | 160.8 | 0 | 0/0 | 0 | 6526 | 162 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.86 | 99.29 | 0.73 | 42.9 | 125.3 | 0 | 0/0 | 0 | 5855 | 143 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.86 | 99.00 | 1.12 | 41.6 | 122.9 | 0 | 0/0 | 0 | 6362 | 153 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.84 | 99.21 | 2.82 | 24.3 | 74.3 | 0 | 0/0 | 0 | 6055 | 166 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.86 | 99.29 | 0.66 | 25.4 | 76.8 | 0 | 0/0 | 0 | 5681 | 144 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.88 | 99.25 | 0.45 | 25.2 | 75.5 | 0 | 0/0 | 0 | 5907 | 149 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
