Test Date: 2016-08-18 13:47
Analysis date: 2016-08-18 15:29
X-ray Calibration - Spectrum
| Slope |
avrg Slope |
48.5623125 |
|
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
48.5623125 |
|
| medianSlope |
median Slope |
48.8485 |
|
| minSlope |
min Slope |
44.965 |
|
| maxSlope |
max Slope |
50.752 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
0.515375 |
|
| medianOffset |
median Offset |
-13.2465 |
|
| minOffset |
min Offset |
-168.792 |
|
| maxOffset |
max Offset |
159.45 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
10.914375 |
|
| medianchi2 |
median chi2 |
3.516 |
|
| minchi2 |
min chi2 |
0.001 |
|
| maxchi2 |
max chi2 |
97.384 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
48.4 e- / Vcal
|
0.1 e- / Vcal
|
-18.0 e-
|
10.7 e-
|
|
1
|
45.0 e- / Vcal
|
0.1 e- / Vcal
|
-44.8 e-
|
9.5 e-
|
|
2
|
46.2 e- / Vcal
|
0.2 e- / Vcal
|
37.9 e-
|
23.1 e-
|
|
3
|
49.2 e- / Vcal
|
0.1 e- / Vcal
|
-123.8 e-
|
17.5 e-
|
|
4
|
49.9 e- / Vcal
|
0.1 e- / Vcal
|
-8.5 e-
|
16.7 e-
|
|
5
|
49.7 e- / Vcal
|
0.1 e- / Vcal
|
159.4 e-
|
9.1 e-
|
|
6
|
47.5 e- / Vcal
|
0.1 e- / Vcal
|
-168.8 e-
|
11.0 e-
|
|
7
|
50.8 e- / Vcal
|
0.1 e- / Vcal
|
-3.4 e-
|
9.1 e-
|
|
8
|
48.2 e- / Vcal
|
0.1 e- / Vcal
|
113.6 e-
|
9.6 e-
|
|
9
|
50.2 e- / Vcal
|
0.1 e- / Vcal
|
-30.9 e-
|
11.1 e-
|
|
10
|
50.0 e- / Vcal
|
0.2 e- / Vcal
|
105.9 e-
|
17.0 e-
|
|
11
|
49.2 e- / Vcal
|
0.2 e- / Vcal
|
122.4 e-
|
18.6 e-
|
|
12
|
48.5 e- / Vcal
|
0.1 e- / Vcal
|
-18.8 e-
|
9.4 e-
|
|
13
|
47.8 e- / Vcal
|
0.2 e- / Vcal
|
-51.2 e-
|
23.0 e-
|
|
14
|
47.1 e- / Vcal
|
0.2 e- / Vcal
|
-76.3 e-
|
19.8 e-
|
|
15
|
49.3 e- / Vcal
|
0.1 e- / Vcal
|
13.5 e-
|
10.9 e-
|
|
Average
|
48.6 e- / Vcal
|
|
0.5 e-
|
|
|
Median
|
99.0 e- / Vcal
|
|
110.2 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
