Test Date: 2016-08-18 13:47
Analysis date: 2016-08-18 15:26
Analysis date: 2016-08-18 15:26
M4365 XRayHRQualification
Summary
| Module | Module | M4365 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 156 | |
| BumpBondingDefects | Bump Bonding Defects | 147 | |
| NoisyPixels | Noisy Pixels | 7 | |
| HotPixelDefects | Hot Pixels | 3 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.83/99.05 | % |
| Noise | Mean Noise | 175 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
10 | 0 | 99.84 | 99.14 | 0.48 | 28.9 | 97.9 | 10 | 0/0 | 0 | 2040 | 181 | 0 |
|
Chip 1
|
A
|
16 | 0 | 99.83 | 99.20 | 1.52 | 31.7 | 107.8 | 14 | 0/0 | 0 | 2026 | 181 | 1 |
|
Chip 2
|
A
|
3 | 0 | 99.83 | 99.20 | 1.05 | 28.7 | 98.3 | 3 | 0/0 | 0 | 1988 | 189 | 0 |
|
Chip 3
|
A
|
24 | 0 | 99.84 | 99.00 | 0.72 | 45.0 | 148.7 | 22 | 0/0 | 0 | 2114 | 164 | 2 |
|
Chip 4
|
A
|
10 | 0 | 99.84 | 99.20 | 0.96 | 48.2 | 160.1 | 10 | 0/0 | 0 | 2117 | 175 | 0 |
|
Chip 5
|
A
|
12 | 0 | 99.82 | 98.96 | 1.03 | 58.3 | 188.7 | 10 | 0/0 | 0 | 2120 | 172 | 2 |
|
Chip 6
|
A
|
6 | 0 | 99.82 | 98.96 | 0.75 | 53.3 | 175.8 | 5 | 0/0 | 0 | 2185 | 167 | 0 |
|
Chip 7
|
A
|
11 | 0 | 99.82 | 98.98 | 1.02 | 57.8 | 191.5 | 11 | 0/0 | 0 | 2190 | 182 | 0 |
|
Chip 8
|
A
|
1 | 0 | 99.86 | 99.31 | 0.57 | 54.3 | 179.9 | 1 | 0/0 | 0 | 2237 | 179 | 0 |
|
Chip 9
|
A
|
4 | 0 | 99.87 | 99.22 | 0.76 | 50.6 | 167.8 | 4 | 0/0 | 0 | 2191 | 169 | 0 |
|
Chip 10
|
A
|
25 | 0 | 99.83 | 98.99 | 0.65 | 55.7 | 180.2 | 24 | 0/0 | 0 | 2192 | 169 | 1 |
|
Chip 11
|
A
|
2 | 0 | 99.84 | 98.95 | 0.6 | 46.8 | 154.8 | 2 | 0/0 | 0 | 2183 | 167 | 0 |
|
Chip 12
|
A
|
7 | 0 | 99.82 | 98.94 | 0.77 | 45.1 | 148.4 | 7 | 0/0 | 0 | 2180 | 172 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.82 | 98.93 | 0.97 | 27.9 | 95.3 | 1 | 0/0 | 0 | 2040 | 174 | 0 |
|
Chip 14
|
A
|
11 | 0 | 99.82 | 98.91 | 0.65 | 29.8 | 101.5 | 11 | 0/0 | 0 | 2095 | 174 | 0 |
|
Chip 15
|
A
|
13 | 0 | 99.82 | 98.89 | 0.7 | 27.2 | 93.3 | 12 | 0/0 | 0 | 2012 | 183 | 1 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-08-18 | |
| TestTime | Test Time | 13:47 | |
| TestDuration | Duration | 1:19:43 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
