Test Date: 2016-08-18 11:13
Analysis date: 2016-08-18 13:25
X-ray Calibration - Spectrum
| Slope |
avrg Slope |
49.22025 |
|
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
49.22025 |
|
| medianSlope |
median Slope |
49.079 |
|
| minSlope |
min Slope |
44.311 |
|
| maxSlope |
max Slope |
53.586 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
-1.7575 |
|
| medianOffset |
median Offset |
-20.3935 |
|
| minOffset |
min Offset |
-110.453 |
|
| maxOffset |
max Offset |
167.969 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
2.9543125 |
|
| medianchi2 |
median chi2 |
1.73 |
|
| minchi2 |
min chi2 |
0.088 |
|
| maxchi2 |
max chi2 |
18.336 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
48.2 e- / Vcal
|
0.2 e- / Vcal
|
-110.5 e-
|
20.3 e-
|
|
1
|
51.5 e- / Vcal
|
0.1 e- / Vcal
|
-76.8 e-
|
11.6 e-
|
|
2
|
48.8 e- / Vcal
|
0.2 e- / Vcal
|
-7.0 e-
|
23.3 e-
|
|
3
|
50.9 e- / Vcal
|
0.2 e- / Vcal
|
-13.9 e-
|
19.7 e-
|
|
4
|
51.2 e- / Vcal
|
0.2 e- / Vcal
|
-51.4 e-
|
18.4 e-
|
|
5
|
45.3 e- / Vcal
|
0.1 e- / Vcal
|
94.0 e-
|
8.4 e-
|
|
6
|
50.5 e- / Vcal
|
0.2 e- / Vcal
|
168.0 e-
|
18.8 e-
|
|
7
|
53.6 e- / Vcal
|
0.1 e- / Vcal
|
-46.2 e-
|
12.7 e-
|
|
8
|
52.1 e- / Vcal
|
0.1 e- / Vcal
|
-59.6 e-
|
12.0 e-
|
|
9
|
52.2 e- / Vcal
|
0.1 e- / Vcal
|
-61.2 e-
|
10.2 e-
|
|
10
|
49.0 e- / Vcal
|
0.2 e- / Vcal
|
103.4 e-
|
19.1 e-
|
|
11
|
49.2 e- / Vcal
|
0.2 e- / Vcal
|
-90.4 e-
|
19.3 e-
|
|
12
|
46.9 e- / Vcal
|
0.1 e- / Vcal
|
-1.3 e-
|
9.7 e-
|
|
13
|
46.8 e- / Vcal
|
0.2 e- / Vcal
|
68.3 e-
|
23.3 e-
|
|
14
|
47.2 e- / Vcal
|
0.2 e- / Vcal
|
-26.9 e-
|
20.1 e-
|
|
15
|
44.3 e- / Vcal
|
0.1 e- / Vcal
|
83.3 e-
|
13.7 e-
|
|
Average
|
49.2 e- / Vcal
|
|
-1.8 e-
|
|
|
Median
|
105.6 e- / Vcal
|
|
-105.8 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
