Test Date: 2016-08-18 11:13
Analysis date: 2016-08-18 13:25
Analysis date: 2016-08-18 13:25
M4115 XRayHRQualification
Summary
| Module | Module | M4115 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 5 | |
| BumpBondingDefects | Bump Bonding Defects | 4 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.05 | % |
| Noise | Mean Noise | 171 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.82 | 98.86 | 0.82 | 21.4 | 73.1 | 0 | 0/0 | 0 | 2006 | 179 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.85 | 99.16 | 0.65 | 22.6 | 77.5 | 0 | 0/0 | 0 | 2006 | 165 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 98.92 | 0.57 | 20.5 | 70.8 | 0 | 0/0 | 0 | 1972 | 173 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.86 | 99.28 | 0.39 | 34.0 | 113.2 | 0 | 0/0 | 0 | 2070 | 166 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.85 | 99.06 | 0.64 | 34.9 | 117.1 | 0 | 0/0 | 0 | 2087 | 162 | 0 |
|
Chip 5
|
A
|
1 | 0 | 99.85 | 99.02 | 0.75 | 43.9 | 143.3 | 1 | 0/0 | 0 | 2129 | 181 | 0 |
|
Chip 6
|
A
|
2 | 0 | 99.82 | 98.98 | 0.91 | 41.4 | 136.6 | 2 | 0/0 | 0 | 2133 | 162 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.86 | 99.28 | 0.53 | 44.1 | 146.0 | 0 | 0/0 | 0 | 2109 | 165 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.86 | 98.97 | 0.54 | 39.7 | 132.2 | 0 | 0/0 | 0 | 2097 | 163 | 0 |
|
Chip 9
|
A
|
1 | 0 | 99.88 | 99.31 | 0.47 | 38.7 | 127.5 | 1 | 0/0 | 0 | 2065 | 167 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.86 | 99.17 | 0.59 | 40.8 | 133.2 | 0 | 0/0 | 0 | 2117 | 167 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.86 | 99.03 | 0.62 | 33.3 | 111.6 | 0 | 0/0 | 0 | 2071 | 169 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.82 | 98.98 | 0.57 | 31.6 | 105.5 | 0 | 0/0 | 0 | 2046 | 174 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.85 | 98.96 | 0.47 | 18.6 | 64.4 | 0 | 0/0 | 0 | 1910 | 180 | 1 |
|
Chip 14
|
A
|
0 | 0 | 99.83 | 98.94 | 0.62 | 20.0 | 69.3 | 0 | 0/0 | 0 | 2005 | 174 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.84 | 98.96 | 0.64 | 18.5 | 64.3 | 0 | 0/0 | 0 | 1970 | 187 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-08-18 | |
| TestTime | Test Time | 11:13 | |
| TestDuration | Duration | 1:20:7 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
