Test Date: 2015-12-11 15:01
Analysis date: 2015-12-15 10:01
Analysis date: 2015-12-15 10:01
M4080 XRayHRQualification
Summary
| Module | Module | M4080 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 18 | |
| BumpBondingDefects | Bump Bonding Defects | 15 | |
| NoisyPixels | Noisy Pixels | 3 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.83/99.07 | % |
| Noise | Mean Noise | 171 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.84 | 98.87 | 0.61 | 20.6 | 70.0 | 0 | 0/0 | 0 | 1984 | 177 | 0 |
|
Chip 1
|
A
|
4 | 0 | 99.87 | 99.23 | 0.44 | 21.6 | 74.4 | 4 | 0/0 | 0 | 1964 | 172 | 0 |
|
Chip 2
|
A
|
3 | 0 | 99.83 | 98.96 | 0.46 | 21.1 | 71.7 | 3 | 0/0 | 0 | 1926 | 196 | 0 |
|
Chip 3
|
A
|
2 | 0 | 99.83 | 98.99 | 0.76 | 35.3 | 115.8 | 0 | 0/0 | 0 | 1998 | 172 | 2 |
|
Chip 4
|
A
|
1 | 0 | 99.83 | 98.99 | 0.55 | 37.1 | 122.2 | 1 | 0/0 | 0 | 2076 | 164 | 0 |
|
Chip 5
|
A
|
1 | 0 | 99.87 | 99.16 | 0.77 | 43.7 | 141.4 | 1 | 0/0 | 0 | 2124 | 161 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.53 | 99.24 | 165.19 | 43.3 | 141.2 | 0 | 0/0 | 0 | 2129 | 166 | 0 |
|
Chip 7
|
A
|
1 | 0 | 99.86 | 99.20 | 0.65 | 42.7 | 140.2 | 0 | 0/0 | 0 | 2059 | 158 | 1 |
|
Chip 8
|
A
|
0 | 0 | 99.84 | 99.00 | 0.54 | 48.5 | 157.8 | 0 | 0/0 | 0 | 2138 | 158 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.89 | 99.22 | 1.13 | 48.1 | 155.6 | 0 | 0/0 | 0 | 2145 | 169 | 0 |
|
Chip 10
|
A
|
1 | 0 | 99.84 | 98.99 | 1.01 | 49.3 | 157.8 | 1 | 0/0 | 0 | 2156 | 159 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.86 | 99.24 | 0.67 | 42.1 | 137.4 | 0 | 0/0 | 0 | 2103 | 165 | 0 |
|
Chip 12
|
A
|
2 | 0 | 99.87 | 99.26 | 0.62 | 37.5 | 122.7 | 2 | 0/0 | 0 | 2087 | 158 | 0 |
|
Chip 13
|
A
|
2 | 0 | 99.82 | 98.92 | 0.75 | 24.4 | 81.7 | 2 | 0/0 | 0 | 2002 | 178 | 0 |
|
Chip 14
|
A
|
1 | 0 | 99.82 | 98.99 | 0.63 | 26.1 | 87.9 | 1 | 0/0 | 0 | 1975 | 196 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 98.87 | 0.80 | 23.6 | 79.1 | 0 | 0/0 | 0 | 1986 | 188 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 44 | |
| nWarnings | # Warnings | 2 | |
| channel_0_count | Channel 0 | 2 | |
| channel_1_count | Channel 1 | 4 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 4 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 2 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
MoReWeb-v0.6.7-111-gcc5e703 on branch 20151208_Readback
