Test Date: 2015-12-11 15:01
Analysis date: 2015-12-15 09:53
Analysis date: 2015-12-15 09:53
M4078 XRayHRQualification
Summary
| Module | Module | M4078 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 5 | |
| BumpBondingDefects | Bump Bonding Defects | 5 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.06 | % |
| Noise | Mean Noise | 165 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.89 | 99.00 | 1.37 | 27.8 | 93.5 | 1 | 0/0 | 0 | 2044 | 171 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.86 | 99.09 | 0.84 | 30.9 | 104.2 | 0 | 0/0 | 0 | 2059 | 179 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.78 | 98.74 | 7.14 | 27.6 | 94.3 | 0 | 0/0 | 0 | 1962 | 182 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.84 | 98.93 | 0.74 | 49.1 | 159.3 | 0 | 0/0 | 0 | 2168 | 166 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.86 | 99.22 | 0.69 | 51.0 | 165.5 | 0 | 0/0 | 0 | 2155 | 158 | 0 |
|
Chip 5
|
A
|
2 | 0 | 99.83 | 98.96 | 0.81 | 61.8 | 197.2 | 2 | 0/0 | 0 | 2209 | 162 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.13 | 0.74 | 58.3 | 188.5 | 0 | 0/0 | 0 | 2201 | 163 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.85 | 99.30 | 0.84 | 63.2 | 203.5 | 0 | 0/0 | 0 | 2255 | 158 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.87 | 99.29 | 0.81 | 63.2 | 204.2 | 0 | 0/0 | 0 | 2222 | 159 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.26 | 0.62 | 57.3 | 186.1 | 0 | 0/0 | 0 | 2180 | 149 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.85 | 99.26 | 1.30 | 62.1 | 198.8 | 0 | 0/0 | 0 | 2227 | 152 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.84 | 98.99 | 0.84 | 53.2 | 172.5 | 0 | 0/0 | 0 | 2167 | 165 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.85 | 98.98 | 0.88 | 47.1 | 154.1 | 0 | 0/0 | 0 | 2133 | 157 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.83 | 98.71 | 8.11 | 29.9 | 101.5 | 1 | 0/0 | 0 | 2016 | 182 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 98.97 | 0.79 | 31.1 | 105.2 | 0 | 0/0 | 0 | 2022 | 166 | 0 |
|
Chip 15
|
A
|
1 | 0 | 99.88 | 99.18 | 1.15 | 30.1 | 100.8 | 1 | 0/0 | 0 | 2032 | 178 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
