Test Date: 2015-12-11 15:01
Analysis date: 2016-01-07 14:17
Analysis date: 2016-01-07 14:17
M4076 XRayHRQualification
Summary
| Module | Module | M4076 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 52 | |
| BumpBondingDefects | Bump Bonding Defects | 51 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.05 | % |
| Noise | Mean Noise | 170 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.84 | 98.95 | 0.42 | 21.6 | 74.4 | 0 | 0/0 | 0 | 1942 | 180 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.84 | 99.02 | 0.72 | 24.3 | 83.5 | 0 | 0/0 | 0 | 1995 | 181 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.84 | 98.87 | 0.53 | 22.9 | 78.5 | 0 | 0/0 | 0 | 1955 | 184 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.84 | 98.97 | 0.96 | 39.8 | 130.5 | 0 | 0/0 | 0 | 2080 | 176 | 0 |
|
Chip 4
|
A
|
1 | 0 | 99.86 | 99.26 | 0.42 | 42.5 | 138.9 | 0 | 0/0 | 0 | 2085 | 171 | 1 |
|
Chip 5
|
A
|
0 | 0 | 99.86 | 99.26 | 0.58 | 50.2 | 161.2 | 0 | 0/0 | 0 | 2151 | 166 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.84 | 98.99 | 0.82 | 47.1 | 153.3 | 0 | 0/0 | 0 | 2135 | 155 | 0 |
|
Chip 7
|
A
|
33 | 0 | 99.85 | 99.06 | 0.83 | 52.0 | 169.4 | 33 | 0/0 | 0 | 2156 | 160 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.83 | 98.92 | 0.98 | 50.2 | 162.3 | 0 | 0/0 | 0 | 2176 | 169 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.29 | 0.61 | 44.3 | 144.4 | 0 | 0/0 | 0 | 2111 | 168 | 0 |
|
Chip 10
|
A
|
1 | 0 | 99.86 | 99.29 | 0.42 | 45.8 | 147.7 | 1 | 0/0 | 0 | 2110 | 171 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.85 | 98.97 | 0.61 | 39.3 | 129.0 | 0 | 0/0 | 0 | 2075 | 185 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.85 | 98.95 | 0.69 | 33.9 | 112.5 | 0 | 0/0 | 0 | 2038 | 157 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.84 | 99.24 | 0.76 | 20.1 | 69.2 | 0 | 0/0 | 0 | 1960 | 165 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.83 | 98.89 | 0.58 | 21.6 | 74.5 | 0 | 0/0 | 0 | 1965 | 167 | 0 |
|
Chip 15
|
A
|
17 | 0 | 99.85 | 98.94 | 0.69 | 19.1 | 66.3 | 17 | 0/0 | 0 | 1930 | 165 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
MoReWeb-v0.6.7-126-g20f70e8 on branch dev-v0.7.0
