Test Date: 2015-11-23 13:32
Analysis date: 2015-11-23 18:15
Analysis date: 2015-11-23 18:15
M4570 XRayHRQualification
Summary
| Module | Module | M4570 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 4 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 4 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.80/99.06 | % |
| Noise | Mean Noise | 180 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
2 | 0 | 99.86 | 98.95 | 0.26 | 13.3 | 43.9 | 0 | 0/0 | 0 | 1801 | 178 | 2 |
|
Chip 1
|
A
|
0 | 0 | 99.88 | 99.20 | 0.27 | 14.0 | 47.2 | 0 | 0/0 | 0 | 1864 | 169 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.03 | 0.63 | 12.3 | 41.6 | 0 | 0/0 | 0 | 1873 | 168 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.85 | 99.04 | 0.65 | 22.7 | 73.3 | 0 | 0/0 | 0 | 1917 | 191 | 0 |
|
Chip 4
|
A
|
1 | 0 | 99.84 | 99.02 | 0.72 | 23.8 | 77.1 | 0 | 0/0 | 0 | 1917 | 185 | 1 |
|
Chip 5
|
A
|
0 | 0 | 99.86 | 99.27 | 0.82 | 29.3 | 93.5 | 0 | 0/0 | 0 | 1984 | 191 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.86 | 99.26 | 0.78 | 27.9 | 89.8 | 0 | 0/0 | 0 | 2008 | 179 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.84 | 99.20 | 0.93 | 28.7 | 92.5 | 0 | 0/0 | 0 | 2000 | 179 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.86 | 99.29 | 1.09 | 29.6 | 96.5 | 0 | 0/0 | 0 | 2007 | 183 | 0 |
|
Chip 9
|
A
|
1 | 0 | 99.84 | 99.28 | 0.73 | 28.5 | 92.2 | 0 | 0/0 | 0 | 2008 | 165 | 1 |
|
Chip 10
|
A
|
0 | 0 | 99.81 | 99.02 | 1.06 | 30.4 | 97.2 | 0 | 0/0 | 0 | 2021 | 176 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.82 | 99.01 | 0.57 | 27.6 | 88.7 | 0 | 0/0 | 0 | 1998 | 193 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.83 | 99.01 | 0.93 | 24.3 | 78.7 | 0 | 0/0 | 0 | 1967 | 191 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.08 | 98.19 | 64.79 | 14.5 | 48.5 | 0 | 0/0 | 0 | 1892 | 184 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.86 | 98.86 | 0.39 | 16.1 | 53.5 | 0 | 0/0 | 0 | 1904 | 178 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.85 | 99.28 | 0.37 | 14.0 | 46.5 | 0 | 0/0 | 0 | 1899 | 164 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
MoReWeb-v0.6.7-73-g24fed82
on branch dev-v0.7.0
