Test Date: 2015-09-07 15:59
Analysis date: 2015-11-23 18:00
Analysis date: 2015-11-23 18:00
M4562 XRayHRQualification
Summary
| Module | Module | M4562 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 4 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 3 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.22 | % |
| Noise | Mean Noise | 174 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.86 | 99.25 | 0.79 | 127.8 | 0 | 43.2 | 0/0 | 0 | 1972 | 177 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.06 | 0.99 | 133.6 | 0 | 45.2 | 0/0 | 0 | 1961 | 191 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.86 | 99.21 | 0.64 | 108.6 | 0 | 36.7 | 0/0 | 0 | 1968 | 178 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.87 | 99.23 | 0.69 | 167.6 | 0 | 56.6 | 0/0 | 0 | 2096 | 166 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.85 | 99.26 | 0.71 | 168.0 | 0 | 56.8 | 0/0 | 0 | 2038 | 188 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.26 | 0.48 | 178.6 | 0 | 60.4 | 0/0 | 0 | 2086 | 179 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.89 | 99.30 | 0.56 | 159.3 | 0 | 53.8 | 0/0 | 0 | 2072 | 176 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.85 | 99.27 | 0.45 | 159.0 | 0 | 53.4 | 0/0 | 0 | 2032 | 174 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.86 | 99.30 | 0.53 | 170.0 | 0 | 57.3 | 0/0 | 0 | 2103 | 174 | 0 |
|
Chip 9
|
A
|
4 | 0 | 99.84 | 99.08 | 0.43 | 168.8 | 1 | 57.1 | 0/0 | 0 | 2095 | 151 | 3 |
|
Chip 10
|
A
|
0 | 0 | 99.84 | 99.29 | 0.68 | 193.4 | 0 | 65.5 | 0/0 | 0 | 2127 | 170 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.88 | 99.28 | 0.72 | 176.8 | 0 | 59.9 | 0/0 | 0 | 2097 | 155 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.84 | 99.25 | 0.55 | 182.6 | 0 | 62.0 | 0/0 | 0 | 2121 | 189 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 98.96 | 0.50 | 122.8 | 0 | 41.6 | 0/0 | 0 | 1956 | 175 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.86 | 99.25 | 0.82 | 141.2 | 0 | 47.8 | 0/0 | 0 | 2014 | 175 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.86 | 99.29 | 0.58 | 142.7 | 0 | 48.4 | 0/0 | 0 | 2059 | 162 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 35 | |
| channel_0_count | Channel 0 | 23 | |
| channel_1_count | Channel 1 | 26 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 10 | |
| message_eventid_count | Event ID mismatch | 2 | |
| message_readback_count | Readback start marker | 35 | |
| message_notokenpass_count | has NoTokenPass | 2 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
