Test Date: 2015-11-23 11:06
Analysis date: 2015-11-23 17:48
Analysis date: 2015-11-23 17:48
M4560 XRayHRQualification
Summary
| Module | Module | M4560 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 0 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.84/99.10 | % |
| Noise | Mean Noise | 177 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.84 | 98.91 | 0.67 | 17.6 | 59.0 | 0 | 0/0 | 0 | 1932 | 170 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.84 | 98.94 | 0.47 | 19.4 | 65.2 | 0 | 0/0 | 0 | 1879 | 185 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 98.96 | 0.46 | 16.9 | 58.2 | 0 | 0/0 | 0 | 1922 | 172 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.84 | 98.99 | 0.90 | 27.9 | 92.0 | 0 | 0/0 | 0 | 1973 | 166 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.84 | 99.09 | 0.68 | 31.1 | 102.2 | 0 | 0/0 | 0 | 2012 | 184 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.84 | 99.28 | 0.61 | 36.9 | 118.8 | 0 | 0/0 | 0 | 2082 | 175 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.86 | 99.31 | 0.88 | 34.5 | 112.6 | 0 | 0/0 | 0 | 2066 | 180 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.85 | 99.20 | 1.13 | 38.6 | 125.2 | 0 | 0/0 | 0 | 2076 | 174 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.85 | 99.00 | 0.75 | 34.4 | 113.2 | 0 | 0/0 | 0 | 2051 | 167 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.33 | 0.56 | 36.4 | 117.9 | 0 | 0/0 | 0 | 2052 | 188 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.83 | 98.98 | 0.72 | 38.1 | 121.7 | 0 | 0/0 | 0 | 2091 | 173 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.84 | 99.21 | 0.83 | 31.3 | 102.2 | 0 | 0/0 | 0 | 2035 | 176 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.85 | 99.26 | 0.53 | 29.8 | 96.9 | 0 | 0/0 | 0 | 2034 | 180 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 99.01 | 0.48 | 18.2 | 61.7 | 0 | 0/0 | 0 | 1927 | 183 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 98.93 | 0.43 | 19.8 | 66.1 | 0 | 0/0 | 0 | 1943 | 178 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.87 | 99.21 | 0.42 | 18.6 | 61.5 | 0 | 0/0 | 0 | 1944 | 180 | 0 |
Errors
| nCriticals | # Criticals | 1 | |
| nErrors | # Errors | 441 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 193 | |
| channel_1_count | Channel 1 | 224 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 181 | |
| message_eventid_count | Event ID mismatch | 180 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 56 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 1 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
