Test Date: 2015-11-23 11:06
Analysis date: 2015-11-23 17:26
Analysis date: 2015-11-23 17:26
M4553 XRayHRQualification
Summary
| Module | Module | M4553 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 6 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 5 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.14 | % |
| Noise | Mean Noise | 179 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.85 | 98.91 | 0.31 | 12.4 | 42.2 | 0 | 0/0 | 0 | 1885 | 172 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.85 | 99.03 | 0.33 | 14.2 | 48.1 | 0 | 0/0 | 0 | 1903 | 176 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.85 | 99.08 | 0.29 | 12.7 | 43.5 | 0 | 0/0 | 0 | 1872 | 176 | 0 |
|
Chip 3
|
A
|
3 | 0 | 99.85 | 99.06 | 0.73 | 20.8 | 68.7 | 0 | 0/0 | 0 | 1873 | 167 | 3 |
|
Chip 4
|
A
|
2 | 0 | 99.87 | 99.39 | 0.39 | 22.6 | 74.6 | 0 | 0/0 | 0 | 1896 | 169 | 2 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.41 | 0.76 | 28.9 | 93.2 | 0 | 0/0 | 0 | 2024 | 186 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.86 | 99.33 | 0.66 | 26.9 | 87.8 | 0 | 0/0 | 0 | 2008 | 174 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.85 | 99.06 | 0.70 | 30.1 | 97.6 | 0 | 0/0 | 0 | 2019 | 179 | 0 |
|
Chip 8
|
A
|
1 | 0 | 99.85 | 99.11 | 0.95 | 25.9 | 85.5 | 1 | 0/0 | 0 | 1962 | 191 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.23 | 0.80 | 25.5 | 83.2 | 0 | 0/0 | 0 | 1978 | 201 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.84 | 99.11 | 0.65 | 26.1 | 84.6 | 0 | 0/0 | 0 | 1981 | 189 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.84 | 99.09 | 1.26 | 20.4 | 67.5 | 0 | 0/0 | 0 | 1914 | 179 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.87 | 99.41 | 0.39 | 19.1 | 63.3 | 0 | 0/0 | 0 | 1926 | 189 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.86 | 99.12 | 0.36 | 10.3 | 35.8 | 0 | 0/0 | 0 | 1858 | 163 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.85 | 99.01 | 0.26 | 12.2 | 41.8 | 0 | 0/0 | 0 | 1887 | 183 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.87 | 98.82 | 0.23 | 10.5 | 36.2 | 0 | 0/0 | 0 | 1862 | 167 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
